RO Drinking Pure Water Treatment Machine Borehole Water Treatment Complete Reverse Osmosis System
- Category: >>>
- Supplier: Guangzhou Vocee Membrane Technology Co. Ltd.
Share on (1600867454974):
Product Overview
Description
Product Description
Water Treatment Reverse Osmosis System Machine
The reverse osmosis method can adapt to all kinds of raw water with salt content, especially in the high-salt water treatment project, it can remove the most bacteria, colloids and large molecular weight organic substances while removing salt. which has good advantages of high salt rejection rate, high recovery rate, stable operation, small floor space and simple operation, obtain good technical and economic benefits.
| Model | WX-RO-1000LPH | Remark |
| Production Capacity | 1000Liter per hour | 24m3 per day |
| Power Supply | 220V/380V 50HZ | Customization |
| Raw Water Pump | 0.75KW | CNP SS304 |
| Quartz Sand Filter | 350*1650MM | FRP |
| Activated Carbon Filter | 350*1650MM | FRP |
| Softener Filter | 350*1650MM | FRP |
| Cartridge Filter | 350*1650MM | FRP |
| High Pressure Pump | 1.5KW | CNP SS304 |
| RO Membrane | 4040 | 4PCS |
| Membrane Housing | 4040 | SS304/FRP |
| Sterilizer Device | UV or Ozone | Optional |
What's the reverse osmosis water treatment plant?
Reverse osmosis process uses semi permeable spiral wound membranes to separate and remove dissolved solids, organic, pyrogen, colloidal matter and bacteria from water. Feed water is delivered under a pressure of approximately 0.9Mpa~1.5Mpa through reverse osmosis membranes. Water permeates the fine pores of the membrane and is delivered as purified water. Impurities in the water are concentrated in the reject stream and flushed to drain. Reverse osmosis is capable of removing 96%-99% of total dissolved solids (TDS), 99% of organic matter, including pyrogen, and 99% bacterial in the feed water.
RO system is widely used in water treatment, purification for tap water, well water, underground water, borehole salty water, brackish water and seawater, pure water and ultra-pure water production. Application area such as, food processing, bottled drinking water, home use drinking water, power stations, electronic industries, cosmetics production, pharmaceuticals manufactories, and medical treatment(such as hemodialysis). It is a key equipment for pure water plant and ultrapure water equipment.
1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter/softener.
2. Multi-medium filter--get rid of turbidity, suspended matter, organic matter, colloid, etc.
3. Active Carbon filter--Remove the color, smell, free chloride, organic matter, harmful matter, etc.
4. Softener--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um,
6. High pressure pump--Provide the high pressure to RO membrane.
7. RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.
2. Multi-medium filter--get rid of turbidity, suspended matter, organic matter, colloid, etc.
3. Active Carbon filter--Remove the color, smell, free chloride, organic matter, harmful matter, etc.
4. Softener--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um,
6. High pressure pump--Provide the high pressure to RO membrane.
7. RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.
Wide Range of Applications
It can be widely used in food, beverage, Electroplating, electronics, optics, chemicals, semiconductors, cosmetics, thermal power plants, metallurgy, light industry, automobile manufacturing, pharmaceutical, medical, industrial water and other fields.
