Product Overview
Description
CNC LATHES FEATURES:
The guideways are hardened and precision ground·Infinitely variable speed change for
spindle. The system is high in rigidity and accuracy. The machine can smoothly run with low noise. Design of electromechanical integration, easy operation and maintenance.
It can turn taper surface, cylindrical surface, arc surface, internal hole, slots, threads, etc., and is used especially for mass
production of disc parts and short shaft in the lines of automobile and motorcycle.
The guideways are hardened and precision ground·Infinitely variable speed change for
spindle. The system is high in rigidity and accuracy. The machine can smoothly run with low noise. Design of electromechanical integration, easy operation and maintenance.
It can turn taper surface, cylindrical surface, arc surface, internal hole, slots, threads, etc., and is used especially for mass
production of disc parts and short shaft in the lines of automobile and motorcycle.
Main specifications:
SPECIFICATIONS | CAK6140 | CAK6150 | |
Max .Swing over bed | 400mm | 500mm | |
Max. Work piece Length | 750/1000/1500/2000/3000mm | ||
Spindle taper | MT6(Φ90 1:20) | ||
Chuck size | C6 (D8) | ||
Thru-hole of spindle | 52mm(80mm) | ||
Spindle speeds (12steps) | 21-1620rpm(I 162-1620 II 66-660 III 21-210) | ||
Tailstock center sleeve travel | 150mm | ||
Tailstock center sleeve taper | MT5 | ||
Repeatability error | 0.01mm | ||
X/Z rapid traverse | 3/6m/min | ||
Spindle motor | 7.5kw | ||
Packing size 750 | 2440×1450×1700mm | ||
Packing dimensions 1000 | 2650×1450×1700mm | ||
Packing dimensions1500 | 3150×1450×1700mm | ||
Packing dimensions2000 | 3610×1450×1700mm | ||
Packing dimensions3000 | 4610×1450×1700mm | ||
Length | G.W. / N.W. | G.W. / N.W. | |
Weight(kg) for 750 | 2100/2800 | 2120/2900 | |
Weight(kg) for 1000 | 2200/2900 | 2240/3000 | |
Weight(kg) for 1500 | 2300/3150 | 2350/3200 | |
Weight(kg) for 2000 | 2700/3350 | 2740/3400 | |
Weight(kg) for 3000 | 3500/4100 | 3600/4200 | |
Sizes of package | 168×114×201cm/193×114×201cm | ||
