Electric Foam Cutter Polystyrene Styrofoam Knife Hot Wire Foam Cutting Knife Portable Styrofoam Cutting Tool Styrofoam Cutting
- Category: >>>
- Supplier: Wu Han Ks Eagle Technology Co. Ltd.Wu Ltd.
Share on (1600868744570):
Product Overview
Description
Product Description
Specification
item | value |
Grade | DIY, Industrial |
Warranty | 1year |
Customized support | OEM, ODM, OBM |
Place of Origin | China |
Fujian | |
Brand Name | KS EAGLE |
Model Number | FC150 |
Rated Voltage | 100-120V/220-240V |
Frequency | 50-60HZ |
Dimensions | 32*24*11CM |
Weight | 1.9KG |
Power Source | Electric |
Product name | hot knife foam cutter |
Application | foam cutter |
Color | red or blue |
Power | 150W |
Keywords | Electric Hot Knife |
Voltage | 100-120V/220-240V |
Name | foam cutter knife |
Cutting material | Sponge Etc |
Function | foam cutter |
Usage | Electric Cutting Machine |
Description:
* Frequency: 50/60HZ
* Temperature adjustment: adjustable
* Blade Max temperature: 600 degree
* Voltage:220V±10%/110v±10%
* Power line length: 3M
* Cutting Range:Suitable for commercial and industrial use, it can cut lightweight foam, KT board pink foam, polyurethane,
polyethylene, expanded polystyrene (EPS) and extruded polystyrene (XPS), styrofoam, polyester foam, sponge etc
* Package size: 32cm*24cm*11cm
* Net weight: 1.9kg
Operation:
- Put your temperature control knob at midrange setting, place the blade against the edge of the foam and depress trigger. Optimum cutting should be virtually smoke free.
- Releasing the trigger approximately one or tow inches prior to the completion of the cut will help keep the blade clean and free from buildup
* Frequency: 50/60HZ
* Temperature adjustment: adjustable
* Blade Max temperature: 600 degree
* Voltage:220V±10%/110v±10%
* Power line length: 3M
* Cutting Range:Suitable for commercial and industrial use, it can cut lightweight foam, KT board pink foam, polyurethane,
polyethylene, expanded polystyrene (EPS) and extruded polystyrene (XPS), styrofoam, polyester foam, sponge etc
* Package size: 32cm*24cm*11cm
* Net weight: 1.9kg
Installation:
NOTE:Always unplug cord of the Thermal Cutter (Hot knife)before installing or removing the blades. Allow sufficient cooling time
for blades, blade holders and metal thumb wheels before handing.
1 - Loosen the screws on the blade holders with the wrench.
2 - Slide the blade under the square pressure plate until snug
3 - Securely tighten screws to assure the proper electrical connection. Do not over-tighten.
4 - Once the blade is firmly in place, plug in the Thermal Cutter (Hot knife) Unit into a standard power supply.
5 - The temperature control knob has 16 click setting that correspond to the graduated ridges on the surface. The smaller the ridge the lower the power setting.
NOTE:Always unplug cord of the Thermal Cutter (Hot knife)before installing or removing the blades. Allow sufficient cooling time
for blades, blade holders and metal thumb wheels before handing.
1 - Loosen the screws on the blade holders with the wrench.
2 - Slide the blade under the square pressure plate until snug
3 - Securely tighten screws to assure the proper electrical connection. Do not over-tighten.
4 - Once the blade is firmly in place, plug in the Thermal Cutter (Hot knife) Unit into a standard power supply.
5 - The temperature control knob has 16 click setting that correspond to the graduated ridges on the surface. The smaller the ridge the lower the power setting.
Caution:
1 - The Thermal Cutter (Hot knife) blade have a sharpened razor edge, for the cleanest cut always cut in the direction on the sharpened edge.
2 - Excessive power output and heat generation may cause the blade holders to overheat resulting in damage to the unit. Use only the power output for proper cutting. The blade does not need to be red hot to move through foamed plastics.
- Always operate the Thermal Cutter (Hot knife)in well ventilated space
- Never burn off excess residue on the hot knife blade. The blades will overheat, warping the blade and potentially overheating the Thermal knife
- Keep hot blades away from skin, clothing and other flammable materials.
- Allow blades to cool before handling. A hot blade may cause injury or burns to exposed surfaces.
NOTE:
- For the best results, practice on scrap pieces of Film&Fabrics .
When cutting foam it is best to keep the temperature and speed consistent. If smoke develops during the cut, you are cutting too slow or the blade is to hot which could result in an over-sized, uneven cut. This can be remedied by lowering the temperature and intermittently releasing the trigger during your cut. As the cutting resistance increases, depress the trigger again. The Thermal Cutter (Hot knife)will reach the set temperature within seconds. You can accomplish your cut with minimal smoke using this process. Cutting in this manner will also prolong the life of the knife.
1 - The Thermal Cutter (Hot knife) blade have a sharpened razor edge, for the cleanest cut always cut in the direction on the sharpened edge.
2 - Excessive power output and heat generation may cause the blade holders to overheat resulting in damage to the unit. Use only the power output for proper cutting. The blade does not need to be red hot to move through foamed plastics.
- Always operate the Thermal Cutter (Hot knife)in well ventilated space
- Never burn off excess residue on the hot knife blade. The blades will overheat, warping the blade and potentially overheating the Thermal knife
- Keep hot blades away from skin, clothing and other flammable materials.
- Allow blades to cool before handling. A hot blade may cause injury or burns to exposed surfaces.
NOTE:
- For the best results, practice on scrap pieces of Film&Fabrics .
When cutting foam it is best to keep the temperature and speed consistent. If smoke develops during the cut, you are cutting too slow or the blade is to hot which could result in an over-sized, uneven cut. This can be remedied by lowering the temperature and intermittently releasing the trigger during your cut. As the cutting resistance increases, depress the trigger again. The Thermal Cutter (Hot knife)will reach the set temperature within seconds. You can accomplish your cut with minimal smoke using this process. Cutting in this manner will also prolong the life of the knife.
Operation:
- Put your temperature control knob at midrange setting, place the blade against the edge of the foam and depress trigger. Optimum cutting should be virtually smoke free.
- Releasing the trigger approximately one or tow inches prior to the completion of the cut will help keep the blade clean and free from buildup
Packing & Delivery
Company Profile
KS EAGLE Technology Co., Ltd is a professional manufacturer of power tools and hand tools that integrates R&D, production, sales and service. Our factory was established in 2008 located in Fujian Province in China, have more than 14 years experience of power tools &hand tools such as Hot Cutter, Siding&Flooring Cutter, Lithium-ion tools and other tools.
KS EAGEL has own brand, also provide ODM and OEM, our products have sent to all over the world such as USA, Canada, Brazil, Mexico, Peru, Japan, South Korea, Philippines, Singapore, UAE, Israel, Germany, Italy, UK, Poland, Finland, Russia, France, Australia, New Zealand, South Africa, Kenya etc.
Choose Ks-Eagle means you will get high quality products, competitve price, excellent service, professional R&D suggestions etc.
We welcome you visit our factory also looking forward to establishing long-time cooperation relationship with you.
KS EAGEL has own brand, also provide ODM and OEM, our products have sent to all over the world such as USA, Canada, Brazil, Mexico, Peru, Japan, South Korea, Philippines, Singapore, UAE, Israel, Germany, Italy, UK, Poland, Finland, Russia, France, Australia, New Zealand, South Africa, Kenya etc.
Choose Ks-Eagle means you will get high quality products, competitve price, excellent service, professional R&D suggestions etc.
We welcome you visit our factory also looking forward to establishing long-time cooperation relationship with you.
FAQ
1. who are we?
We are based in Hubei, China, start from 2020,sell to Eastern Europe(15.00%),Northern Europe(10.00%),Central America(10.00%),Western Europe(10.00%),Southern Europe(10.00%),North America(10.00%),South America(10.00%),Mid East(5.00%),Oceania(5.00%),South Asia(5.00%),Southeast Asia(5.00%),Eastern Asia(3.00%),Africa(2.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Hot Knife,Hot Knife Foam Cutter,Hot Knife Rope cutter,Glue gun,Hot air gun
4. why should you buy from us not from other suppliers?
Wuhan KS EAGLE Technology Co., Ltd. is a professional manufacturer of power tools and hand tools that integrates R&D, production, sales and service. The main products are electric hot knife, cordless caulking gun, laminate flooring cutter
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,FCA,DDP,DDU,Express Delivery,DAF；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Hubei, China, start from 2020,sell to Eastern Europe(15.00%),Northern Europe(10.00%),Central America(10.00%),Western Europe(10.00%),Southern Europe(10.00%),North America(10.00%),South America(10.00%),Mid East(5.00%),Oceania(5.00%),South Asia(5.00%),Southeast Asia(5.00%),Eastern Asia(3.00%),Africa(2.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Hot Knife,Hot Knife Foam Cutter,Hot Knife Rope cutter,Glue gun,Hot air gun
4. why should you buy from us not from other suppliers?
Wuhan KS EAGLE Technology Co., Ltd. is a professional manufacturer of power tools and hand tools that integrates R&D, production, sales and service. The main products are electric hot knife, cordless caulking gun, laminate flooring cutter
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,FCA,DDP,DDU,Express Delivery,DAF；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
