Engine | ||
Name | ZONGSHEN 4-stroke NC300S | |
Model | ZS182MN | |
Type | Single-cylinder, 4-stroke, Water-cooled, 4-valve Overhead double cam, balance shaft type | |
Maximum Power | 23Kw/9000 | |
Maximum Torque | 25N.m/7000 | |
Compression Ratio | 11.6: 1 | |
Bore × Stroke | 82×53.6mm | |
Start Method | Electric+Kick Start | |
Ignition Method | C.D.I. | |
Clutch Type | Wet Multi-Plate | |
Gearshift Method | Constant mesh with two-stage transmission and six-speed transmission | |
Fuel Delivery | Carburetor | |
Lubrication method | Pressure Splash | |
Frame | ||
Length × Width × Height | 2190×850×1300mm | |
Seat Height | 960mm | |
Minimum Ground Clearance | 300mm | |
Wheelbase | 1480mm | |
Vehicle Weight | 118kg | |
Fuel Tank Capacity | 7L | |
Tire Specifications (Front/Rear) | 80/100-21 / 110/100-18 | |
Tire Pressure (Front/Rear) | 225Kpa / 335Kpa | |
Brake Method (Front/Rear) | Disc Brake / Disc Brake | |
Rim Specifications (Front/Rear) | 1.6×21 / 2.15×18 | |
Suspension System | Adjustable front and rear shock absorbers | |
