New Profinet communication protocol remote 4 port I/O sensor 001CA1 narrow module IP67 fieldbus
New Profinet communication protocol remote 4-port I/O sensor 001CA1 narrow module IP67 fieldbus
New Profinet communication protocol remote 4-port I/O sensor 001CA1 narrow module IP67 fieldbus
New Profinet communication protocol remote 4-port I/O sensor 001CA1 narrow module IP67 fieldbus
New Profinet communication protocol remote 4-port I/O sensor 001CA1 narrow module IP67 fieldbus
New Profinet communication protocol remote 4-port I/O sensor 001CA1 narrow module IP67 fieldbus

New Profinet communication protocol remote 4 port I/O sensor 001CA1 narrow module IP67 fieldbus

Share on (1600870575180):


Price:$350.00 - $400.00

Quantity:


Product Overview

Description



Technical Parameter


Rated working voltage UB
18...30VDC
Function indication light
US/UA
Port status indication light
Red，Yellow
Module status indication light:Mod LED
With
Network status indication light
With
Housing material
NP Gd-Zn alloy
Storage temperature
-25...+85 °C
IP Grade conforms to IEC 60529
IP 67
Working temperature Ta
-25...+70 °C
Size
223×65×25.8mm
FIeld bus Connecting
M12 ,A-coded，female plug
Connection :AUX power supply
M12 ，A-coded，Male/Female
I/O port number
8
Port status indication light(signal status)
Yellow LED indication light
Port diagnosis indication light(overload)
Red LED indication light
Fastener
2 pcs Mounting hole


Product Description




For high performance applica-tions, we recommend to consider Profinet IO-Link main control unit port. This port goes through EREC200 and also support isochronous real-time communication(IRT).
This module comprises of 4 IO-Link master port. those ports can be configured and used independently. All IO-Link ports support COM1,COM2 and COM3 port (only suitable for 3-wires) and SIO mode.
IO-link port also has an additional input port or input/output port connected by PIN 2. this means it also can be connected to auxiliary normally open/closed and DESINA sensor at SIO mode.
