High Performance EPC GEN 2 4 Port Integrated For Parkin Uhf Rfid Reader Module
- Category: >>>
- Supplier: Shenzhen Silion Technology Co. Ltd.
Share on (1600875162145):
Product Overview
Description
Product Description
Product Paramenters
Features
A metal frame with industrial design
EPC global Gen2 (ISO 18000-6C)
ethernet port（10/100M), RS232
With Impinj R2000, 33dbm
4 port for antenna connection, PoE power supply, a various choice of interfaces
EPC global Gen2 (ISO 18000-6C)
ethernet port（10/100M), RS232
With Impinj R2000, 33dbm
4 port for antenna connection, PoE power supply, a various choice of interfaces
Physical characteritics | ||
84Dimensions | 183.35mm×56mm×17mm | |
8282Net weight | 82g | |
RFID Characteristics | ||
Air Protocols | EPC Class 1 Gen 2 (ISO 18000-6C) | |
Frequency | USA: 902-928MHz FCC (NA, SA) | |
EU: 865.6-867.6MHz, 869.85MHz | ||
CN: 920-925MHz (CMIIT) | ||
Other customizable: OPEN 840-960MHz | ||
Antenna ports | Four 50Ω reverse TNC Connectors | |
Output Power | 5dBm-33dBm (±1dBm) adjustable | |
Work Mode | Fixed / hop frequency optional | |
Connector Interface | ethernet port（10/100M), RS232 | |
(Power supply, Communication, GPIO) | ||
ASIC | Impinj INDY R2000 | |
RFID Performance | ||
Max Read Rate | ≥400 tags/s | |
Tag Read Distance | ≥10m, 8dbi antenna | |
Certificates | ||
Certificates | In processing | |
Application Interface | ||
Host API | C, C#/.NET, Java | |
Communication Interface | ||
Communications | USB 2.0 or UART serial port (RS232), Baud rate 9600~115200bps | |
GPIO (Optional) | Optional, 2 inputs (DC 0~3.3V), 2 Outputs (DC 0~3.3V) | |
Power Supply | ||
Input Voltage | 12V/3A adatper or PoE | |
Power consumption in RF output mode | 13.5W (Peak Value) | |
Indicator | Power indicator, status indicator, built-in buzzer | |
Working Environment | ||
Operating Temp. | -20°C to +55°C | |
Storage Temp. | -20 °C to +60°C | |
Humidity | 5-90% non-condensing (+25°C) | |
Recommend Products
Company Introduction
Application Fields
Certifications
FAQ
1. Are you manufacturer?
Yes, Silionis one of the pioneering manufacturer focusing on UHF RFID hardware design and manufacture since from 2005.
2. What are your mainly products?
Our products mainly include UHF RFID reader, UHF RFID tag, UHF RFID module R2000 series, UHF RFID module E710 series and RFID
antennas.
3. What is your advantage?
We have served many customers in many application fields, with a wide and rich experience.
we have strong technical team for technical support.
We often provide customized service for special needs.
We have hundreds of UHF RFID modules, the most complete.
4. How to place order to Silion?
You can place order to us through Alibaba trade assurance order online or you can contact our sales for other ways.
We also can accept payment by TT, West Union, credit card or PayPal and other payment methods.
5. How to be your partner or distributor?
Pls contact our oversea sales team for details: sales@silion.com.cn
6. What is the MOQ?
We don’t have MOQ limit, you can buy one sample for testing.
7. Do you have test evaluation board?
Yes, our test evaluation board, also named as DEVKIT, develop kit, which supports all Silion’s UHF RFID module’s testing.
8. Do you have certifications?
Yes, Silion products have applied FCC, CE, SRRC, RoHS and other related certifications.
9. What’s your lead time?
For small orders, we normally have goods in stock, delivery time is very fast, around 2-3 working days after order confirmed; If need to produce, it depends on quantity, pls feel free to contact us to know more.
10. Are you Impinj Gold Partner?
Yes, as our main products are based on Impinj R2000, new E710, E510 and E310, we are authorized by Impinj as Gold partner long time ago.
11. Do you provide after sale service?
Yes, Silion has a professional technical support team, with rich experience in developing and application, we provide full services as customers need. For detailed technical documents, you can directly download from our website, and if any problems, you can feel free to contact us, we can support you by email, voice talk, or fly to your country to support (to be discussed).
