Product Name
|
FusionServer 2288HV6
|
|
2U rack server
|
|
processor
|
1/2 third-generation Intel ® xeon ® Scalable processor (Ice Lake) (8300/6300/5300/4300 series), up to 270W
|
|
Chipset
|
Intel C621A
|
|
Memory
|
32/16 DDR4 memory slots are flexibly selectable, with a maximum of 3200MT/s; Up to 16 Intel ® Aoteng ™ Persistent memory 200
series, up to 3200MT/s
|
|
Local storage
|
Supports multiple different hard drive configurations, and the hard drive supports hot swapping: Configurable with 8-31 2.5-inch
SAS/SATA/SSD hard drives Configurable with 12 to 20 3.5-inch SAS/SATA hard drives Configurable with 4/8/16/24 NVMe SSD disks
Supports up to 45 2.5-inch hard drives or 34 full NVMe SSDs Support for Flash storage: • Dual M.2 SSDs
|
|
RAID support
|
Optional configuration supports RAID0, 1, 10, 5, 50, 6, 60, etc., supports Cache supercapacitor protection, provides RAID level
migration, disk roaming, self diagnosis, and web remote settings Equal function
|
|
network
|
Supports multiple network expansion capabilities Supports OCP 3.0 network cards -2 FLEX IO card slots each supporting 2 OCP 3.0
network cards, supporting on-demand configuration. Supports hot swapping
|
|
PCle extension
|
Up to 14 PCIe 4.0 expansion slots, including 1 PCIe expansion slot dedicated to RAID cards, 2 FLEX IO expansion slots dedicated to
OCP3.0, and 11 standard PCIe 4.0 expansion slots Expansion slot.
|
|
Fan
|
4 hot swappable counter rotating fans, supporting N+1 redundancy
|
|
Power Supply
|
Can be configured with 2 redundant hot swappable power supplies, supporting 1+1 redundancy, with optional specifications as
follows: 900 W AC platinum/titanium power supply (input: 100 V AC to 240 V AC or 192V DC to 288V DC) 1500W AC Platinum Power
Supply 1000W (input: 100V AC~127V AC) 1500W (Input: 200V AC~240V AC or 192V DC~288V DC) 1500W 380V high-voltage DC power supply
(input: 260V DC~400V DC) 1200W -48V~-60V DC power supply (input: -38.4V DC~-72V DC) 3000W AC titanium power supply 2500W (input:
200V AC~220V AC) 2900W (input: 220V AC~230V AC) 3000W (Input: 230V AC~240V AC) 2000W AC Platinum Power Supply 1800W (Input: 200V
AC~220V AC or 192V DC~200V DC) 2000W (Input: 220V AC~240V AC or 200V DC~288V DC)
|
|
Administration
|
The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault
diagnosis, automated operation and maintenance, and hardware security reinforcement. IBMC supports standard interfaces such as
Redfish, SNMP, and IPMI2.0; Provide a remote management interface based on HTML5/VNC KVM; Support monitoring, diagnosis
Out-of-band management functions such as configuration, Agentless, and remote control simplify management complexity Optionally
equipped with FusionDirector management software, providing advanced management features such as five major intelligences,
achieving full lifecycle intelligence, automation, visualization, and refinement Chemical management
|
|
operating system
|
Microsoft Windows Server,SUSE Linux Enterprise Server,VMware ESXi,Red Hat Enterprise Linux,CentOS,Oracle
Ubuntu,Debian,openEuler
|
|
Safety characteristics
|
Support security features such as power on password, administrator password, TPM 2.0, security panel, secure startup, cover
opening detection, etc
|
|
working temperature
|
5ºC - 45ºC(41ºF-113ºF)(ASHRAE Class A1/A2/A3/A4)
|
|
Product certification
|
CE,UL,CCC,FCC, VCCI,RoHS
|
|
apt-get install
|
Support L-shaped slide, retractable slide, and track holding
|
|
Dimensions (H x W x D)
|
3.5-inch hard drive chassis size: 86.1mm × 447 mm × 790 mm 2.5 inch hard drive chassis size: 86.1mm × 447 mm × 790 mm
|
