nitinol or Shape memory alloy austenitic thermal active super elastic niti wire of diameter 0.05 mm to 1.2 mm

Share on (1600877968848):


Price:$21.00 - $28.00

Quantity:


Product Overview

Description



Product Description


Factory supply fishing wire price of nitinol wire price per kg

Nickel Titanium (also known as Nitinol or NiTi) is in the unique class of shape memory alloys.

A thermoelastic martensitic phase transformation in the material is responsible for its extraordinary properties. Nitinol alloys are typically made of 55%-56% Nickel and 44%-45% Titanium. Small changes in composition can significantly impact the properties of the material.


There are two primary categories of Nitinol.

The first, known as "SuperElastic", is characterized by extraordinary recoverable strains and kink resistance.

The second category, "Shape Memory" alloys, is valued for the Nitinol's capacity to recover a pre-set shape when heated above its transformation temprature. The first category is often used for orthodontics (braces, wires, etc) and eyeglasses. SZNK makes shape memory alloys, which are primarily useful for actuators, used in many different mechanical devices.



Product Type
Grade
Fully Annealing Af
Form
Standard
Shape memory nitinol alloy
NiTi-01
20℃~40℃




Wire, Bar, Plate



Customer specified or Industry Standard

(ASTMF2063

Q/XB1516.1

Q/XB1516.2)
NiTi-02
45℃~90℃
Superelastic nitinol alloy
Ni-Ti-SS
-5℃~5℃
Low temperature superelastic nitinol alloy
TN3
-20℃~-30℃
TNC
Medical nitinol alloy
NiTi-SS
Active Af
33℃±3℃
Narrow hysteresis nitinol alloy
NiTiCu
As-Ms≤5℃

Wire, Bar
Wide hysteresis nitinol alloy
NiTiNb
As-Ms<150℃
NiTiFe


size
Wire: Dia.0.05-6.0mm
Bar:Dia3.0mm—20mm
Sheet: Thickness 0.3-10.0mm Width≤400mm Length≤2500mm

Surface State Options
Oxide surface (including black oxide, Blue oxide, Amber oxide)
Etched surface
Medical grade polished surface
Centerless ground surface

Packaging
Straight lengths/ Coils without support
Coils with support/ spools
Wooden cases suitable for overseas shipment
Other packaging available on customer's request


Products Show


There are four commonly used types of applications for nitinol.

1. Free Recovery: nitinol is deformed at a low temperature, and heated to recover its original shape.
2. Constrained Recovery: The same, except that recovery is rigidly prevented, and thus a stress is generated.containers and bottles in all shapes.

3. Work Production: Here the alloy is allowed to recover, but to do so it must act against a force (thus doing work).

4. Superelasticity: As discussed above, here the nitinol acts as a super spring.



Application

cell phone antenna,
children's toys,
experimental materials,
glasses leg,
women bra,
Women's Sports Central,
arch wires,
instruments,
and medical equipment, such as surgical stitching wire,
birth control loop and other areas of high-quality memory alloy wire.











Our Service


Our principle of service is based on respecting, understanding and creating values for our clients.


We will place ourselves in the position of our customers, understanding the need and sentiment of yours, and finding out the potential problems for clients in advance, solving them in the bud and preventing the worsening of problems.


Sincerely we will regard our clients as friends, thinking for your needs and facilitate your business and development, which we are expected to earn the respect and confidence from you in return.




Our concept is to offer solutions to our clients in a responsible manner.

We will complete our tasks and services in the manner of extreme perfection. We follow the rule that any enquiry, appeal or complaint from our clients would be carefully handled. Because we regard offering services as our business, the quality as our lives.


We know slight negligence will harm our clients and leave lasting and spreading depression to our clients, which will do harm to the image of the enterprise as well. That is why we have proposed the concept "fully-committed service". We will apply this standard to serve our clients both old and new to achieve the recognition and contentment from our clients.




Packing & Delivery


Packaging




Packaging Details



Carefully packing with carton case or bubble paper or both kinds together.

Packing as your requirement.


Packaging




Packaging Details



Carefully packing with bubble paper or carton case inside and plywood case outside to avoid any damage.

Packing as your requirement.
