Product Overview
Description
Products Description
Portable Shotcrete Machines Gas Gunite Machine Air Rotor Motor Dry Mix Shotcrete Gunite Concrete Spraying Machine Price
1) Environmental:It can reduce the dust concentration around the machine and the spraying gun when the wet shotcrete machine work,so as to lower the harm to workers’ health.
2) rebound less to strengthen sprayed layer.
3) It can greatly improve the spray quality and the uniformity of concrete--because the water & cement ratio is easy to control when wet Shotcreting, and the concrete curing degree is higher.
4) Unique vibrating hopper feeds the concrete into the dosing system smoothly.
5) Standardized dosing pump can add exactly concrete accelerator.
6) We can change the color according to your actual requirements.
7) Custom the voltage motor based on your country.
8) The tread of mine rail wheel have 600mm or 900mm for your choice.zmwm09
2) rebound less to strengthen sprayed layer.
3) It can greatly improve the spray quality and the uniformity of concrete--because the water & cement ratio is easy to control when wet Shotcreting, and the concrete curing degree is higher.
4) Unique vibrating hopper feeds the concrete into the dosing system smoothly.
5) Standardized dosing pump can add exactly concrete accelerator.
6) We can change the color according to your actual requirements.
7) Custom the voltage motor based on your country.
8) The tread of mine rail wheel have 600mm or 900mm for your choice.zmwm09
Product Paramenters
Portable Shotcrete Machines Gas Gunite Machine Air Rotor Motor Dry Mix Shotcrete Gunite Concrete Spraying Machine Price
Model | PZ-3 | PZ-5 | PZ-7 |
Capacity (m3/h) | 3.5 | 5 | 7 |
Max. Conveying Distance (Horizontal,Vertical m) | 200,20 | 200,20 | 200,20 |
Use material ratio(Cement/Sand) | 2001-3-5 | 2001-3-5 | 2001-3-5 |
Use material water-cement ratio | ≤0.4 | ≤0.4 | ≤0.4 |
Max. Aggregate Diameters (mm) | 20 | 20 | 20 |
Feeding pipe inner diameters(mm) | 38 | 51 | 64 |
Rotor Diameter(mm) | 350 | 438 | 480 |
Working pressure (MPa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
Air consumption (m3/min) | 3-4 | 7-8 | 8-10 |
Motor Model | Y112M-6-3KW | Y132-6-5.5KW | Y132-6-7.5KW |
Voltage(V) (according to customer's special requirement) | 380,660,etc | 380,660,etc | 380,660,etc |
Overall size (mm) | 1040*550*940 | 1280*700*1280 | 1500*700*1280 |
Overall weight (kg) | 260 | 600 | 700 |
