Shenzhen Fr4 94V0 Pcb Manufacturer high frequency hdi PCB Assembly PCBA clone pcb With Provided Bom Gerber Files
- Category: >>>
- Supplier: Gesp Technology (Dalian) Co. Ltd.
Share on (1600881384516):
Product Overview
Description
CAPABILITY | STANDARD | ADVANCED | |
MinimumLayer Count | 1 | 1 | |
Maximum Layer Count | 12 | 40 | |
Material | FR-4 (Tg-135C, 145C, 170C), Halogen- free Rogers Ultralam 2000, Rogers RO4350, Rogers RO4003 Polyimide Black FR-4 Arlon AR-350 CEM-3 Getek Copper Clad Thermal Substrates Hybrid (Rogers and FR4) BT Epoxy Nelco 4013 PTFE Metal Core Materials Aluminum Core | ||
Board Thickness | 0.020"-0.125" | 0.005"-0.250" | |
Maximum Board Size | 16" x 22" 12" x 21" 22" x 28" | 10" x 16" 16" x 22" 12" x 21" 22" x 28" | |
Copper Thickness | 0.5 oz – 3 oz | 0.25 oz – 12 oz | |
Minimum Trace Width / Spacing | 0.004"/0.004" | 0.003"/0.003" | |
Solder Mask Color | Green, Blue, Black, Red, Yellow, White, Clear, and customized | ||
Silkscreen Color | White, Black, Yellow, Green, Red, Blue and customized | ||
Minimum Hole Size | 0.008" | 0.004" | |
Finished Hole Size Tolerance | +/-0.003" | +/-0.002" | |
PCB Surface Finish | HASL (vertical & Horizontal), Lead Free HASL, OSP/Entek, ENIG, ENEPIG, HASL + Gold Finger,Immersion Tin(ISn), Immersion Silver(IAg), Carbon Ink, Hard Gold(Flash Gold), Soft Gold | ||
IPC Class | Class 2 | Class 3 | |
Controlled Impedance Tolerance | +/-10 % | +/-5 % | |
Blind Vias | Yes | Yes | |
Buried Vias | Yes | Yes | |
Aspect Ratio | 8/1 | 15/1 | |
Minimum Core Thickness | 0.004" | 0.002" | |
Carbon Ink | Yes | Yes | |
Peelable Mask | Yes | Yes | |
Solder Sample | Yes | Yes | |
First Article | Yes | Yes | |
ISO 9001: 2008 | Yes | Yes | |
ISO/TS16949: 2009 | Yes | Yes | |
UL 94v0 | Yes | Yes | |
Product details
Company Profile
* PCB order : Please provide Gerber File and manufacturing specifications.
. * PCBA order : Please provide Gerber File, Manufacturing specification, BOM list and Pick & Place/XY file.
* Reverse engineering and PCB copy service can be supplied with your PCB sample.
* PCB design :need detail information about the function or supply the drawing.
. * PCBA order : Please provide Gerber File, Manufacturing specification, BOM list and Pick & Place/XY file.
* Reverse engineering and PCB copy service can be supplied with your PCB sample.
* PCB design :need detail information about the function or supply the drawing.
* Any further question, welcome to contact us by sending inquiries.
