SY V047 Good Quality OCT Machine Ophthalmic Equipment Optical Coherence Tomography Machine for Sale
- Category: >>>
- Supplier: Sunny Medical Equipment LimitedSunny Limited
Share on (1600883643692):
Product Overview
Description
SUNNYMED Reliable Quality Affordable Price
SY-V047 Good Quality OCT Machine Ophthalmic Equipment Optical Coherence Tomography Machine for Sale
Why this model?
Feature of Optical Coherence Tomography OCT Machine Ophthalmic:
All-in-one Design
Compact Design: Everything is inside this compact body. No external computer is needed. Plug in the power cable, then you are ready to go.
PC Inside: Data acquisition and processing are accomplished by the internal computer. The data can be transported via ethernet or external harddrive. Peripheral devices, such as keyboard or printer, can be connected to the computer ports.
Easy Installation: No complex connection or setup. Compact body can fit in even small space.
Affordable Quality
We believe that less is more. The simple design of SY-V047 OCT reduces the cost of the device without sacrificing the image quality. OCT has never been so affordable. More people can benefit from the advanced technology now.
Compact Design: Everything is inside this compact body. No external computer is needed. Plug in the power cable, then you are ready to go.
PC Inside: Data acquisition and processing are accomplished by the internal computer. The data can be transported via ethernet or external harddrive. Peripheral devices, such as keyboard or printer, can be connected to the computer ports.
Easy Installation: No complex connection or setup. Compact body can fit in even small space.
Affordable Quality
We believe that less is more. The simple design of SY-V047 OCT reduces the cost of the device without sacrificing the image quality. OCT has never been so affordable. More people can benefit from the advanced technology now.
Simple Operation
Step 1
Choose left or right eye. Push the direction buttons to move the target eye to the center of the field of view, then start data
acquisition.
Step 2
Enter the data acquisition interface. The device is able to search for the OCT signal and optimize it automatically.
Step 3
Browse and analyze the acquired images.
Step 1
Choose left or right eye. Push the direction buttons to move the target eye to the center of the field of view, then start data
acquisition.
Step 2
Enter the data acquisition interface. The device is able to search for the OCT signal and optimize it automatically.
Step 3
Browse and analyze the acquired images.
Methodology | Spectral domain OCT |
Axial resolution | ≤ 6 um (in tissue) |
Transverse resolution | ≤ 20 um (in tissue) |
Scan depth | ≥ 2.5 mm (in air) |
Scan range | ≥ 6 mm |
Scan speed | ≥ 24,000 A-scans/sec, up to 36,000 A-scans/sec |
Scan modes | 3D, Raster, Circle |
Fundus image | OCT en face |
Focus adjustment | -15D to +15D |
Pupil diameter | ≥ 3 mm |
OCT light source | 840 nm SLD |
Optical power | 750 uw (at cornea) |
Operation | 13.3" touch screen, optional external mouse or keyboard |
Dimension | 497 mm × 395 mm × 490 mm (L×W×H) |
Weight | 34kg |
Packing&Delivery
For more detailed images and videos
please contact with us!
FAQ
1. How to buy?
2. How to pay?
A. Trade assurance
B. Credit Card
C. Paypal in Alibaba
D.T/T(Bank Transfer)
E. Western union
F. L/C
Return policy
3. How long to wait for the order?
A. Ready stock within 24 hours
B. OEM need 2-7 working days
C. Safety delivery:special one-to-one inspection service before arranging the delivery
B. Credit Card
C. Paypal in Alibaba
D.T/T(Bank Transfer)
E. Western union
F. L/C
Return policy
3. How long to wait for the order?
A. Ready stock within 24 hours
B. OEM need 2-7 working days
C. Safety delivery:special one-to-one inspection service before arranging the delivery
4. How to use our product?
A. Video tutorial: including installation, operation, repairing and maintenance
B. Real Time Online Video Call at your convenience: Pre-sales and after-sales online video training
5. Warranty and after-sales service
A.12-60 months
B. After-sales service: Reply within 8 hours
A. Video tutorial: including installation, operation, repairing and maintenance
B. Real Time Online Video Call at your convenience: Pre-sales and after-sales online video training
5. Warranty and after-sales service
A.12-60 months
B. After-sales service: Reply within 8 hours
Why Choose Us
We are based in Guangdong, China, starting from 2014. Products are sold to South America, Southeast Asia, North America, and Africa, ect. .
