Spring Hose Clamp

Product Overview

Description



Spring Hose Clamp

Features:

Spring hose clamp ensures maximum thrust when tightening.

Compact design allows ease of installation,ideal for industrial or home use.

To make sure that you can tighten, you need to buy a clamp that inner diameter is smaller than outer diameter of your pipe.

Material:

Dacromet coating 65Mn steel, Zinc-plated 65Mn steel

Application:

Air hose, water pipe, fuel line, silicone hose, etc.



Diameter (mm)	Band Thickness  (mm)	Band Width  (mm)
4	0.4	4
5	0.6	6
6	0.6	6
7	0.6	6
8	0.7	7
9	0.8	8
9.5	0.8	8
10	0.8	8
10.5	0.8	8
11	0.8	8
11.5	0.8	8
12	0.8	8
12.5	1.0	10
13	1.0	10
13.5	1.0	10
14	1.0	10
14.5	1.0	10
15	1.0	10
16	1.0	12
17	1.0	12
18	1.0	12
19	1.0	12
20	1.0	12
21	1.2	12
22	1.2	12
