MIRAN Split Type Non Contact Hall Magnetic Induction Sensor WOA B Angular Displacement Sensor for Position Measurement
- Category: >>>
- Supplier: Hubei Miran Technology Co. Ltd.
Share on (1600896082285):
Product Overview
Description
Product Description
Miran Hall Angle Sensor WOA-B 0-355 Degrees Split Type Non- contact Angular Displacement Sensor Analog Output
Overview
Overview
The WOA-B series product is used for angular displacement measurement which is made with the principle of the magnetoelectric.
Main Feature
1.Non-contact,High Sensitivity,High Resolution,High Frequence,Low Temperature Drift,Excellent Linearity,etc..
2.Waterproof and Dustproof,can be used in harsh environment.
3.Absolute position measurement，Can be used to replace optical encoders, rotary transformers, conductive plastic potentiometer.
4.Customized angle is allowed during the range 0°～355°，For example:90°、180°、200°...
5.Supply voltage + DC12V-24V for output signal 0 ~ 10V and 4 ~ 20mA.
6.Supply voltage + DC 5V for output signal 0-5V
Detailed Images
Packing & Delivery
1.Lead time:within 7 working days after receive payment.
2.Port: shenzhen
3.Shipping by DHL,TNT, FedEX, USP ,EMS etc.
4.Packing in a pvc tube with foam to ensure the safety of transportation.
Our Company
Since 2003 we have been developed and produced displacement sensors in Shenzhen.In order to meet more customer needs,we expend the scale of production.And set up our new factory in Hubei Province
Zaoyang Miran Technology Co., Ltd. is the professional manufacturer of Linear Position Sensor in China.It's our new factory which is located in Hubei Provice.Our sales headquarters located in Shenzhen.
Zaoyang Miran Technology Co., Ltd. is the professional manufacturer of Linear Position Sensor in China.It's our new factory which is located in Hubei Provice.Our sales headquarters located in Shenzhen.
Our main products are: Linear Position Sensor,Wire Rope Encoder,Magnetostrictive Liquid Level Sensor,Angle Sensor,Inclinometer, Lubricating System(pump and distributors and the other accessories),LVDT sensor,Eddy Current Sensor, and many other motion control products to support many different industries.Our factory is approved by ISO9001:2008, and all our products have CE, CCC certificates.
Our Principles: Quality First, Credit First, Customer First.
Our Advantages
1. Strong capability in Research&Design.We spend million dollars every year for developing new tech and new products.
2. Promise high quality after strict tests. Every product will go through vibration test, low and high temperature test,electromagnetic interference regulatory test,endurance test, and explosion proof test.
3. Strong production capacity. We have factories both in Shenzhen and Hubei Province, and also a lot of in-stock products in warehouses. We can meet large demands from our customers, and deliver the orders on time.
4. Excellent sales & after-sales service. We are headquartered in Shenzhen, and have branches all over China. We guarantee life-long for all products.We can offer you the competitive perfect products.
5.OEM is aviable.We also support to put your logo on the products if you need.
1. Strong capability in Research&Design.We spend million dollars every year for developing new tech and new products.
2. Promise high quality after strict tests. Every product will go through vibration test, low and high temperature test,electromagnetic interference regulatory test,endurance test, and explosion proof test.
3. Strong production capacity. We have factories both in Shenzhen and Hubei Province, and also a lot of in-stock products in warehouses. We can meet large demands from our customers, and deliver the orders on time.
4. Excellent sales & after-sales service. We are headquartered in Shenzhen, and have branches all over China. We guarantee life-long for all products.We can offer you the competitive perfect products.
5.OEM is aviable.We also support to put your logo on the products if you need.
Hope we can build up the long-term and harmonious business relationship!
Welcome to visit us.Any confusion please do not hesitate to contact us!
Wechat/whatsAPP/Phone:86 18988775283
Skype:miranivy
Email:sales5@miran-tech.com
FAQ
Q1: What payment method your company accepts?
A: We accept T/T (Bank Transfer), Western Union, Paypal, Alipay, Wechat pay.
Q2:How long for the production time?
A: Standard products in stock, or 5-7 days depends on order quantity and product type. Exactly time please contact us.
Q3: You said we can use our own logo? What's the MOQ if we wanna do this?
A: Yes, 1 pcs MOQ.We can also offer customized products.
Q4: Can I have a sample products for testing?
A: Yes you can buy sample product.
Q5: Can you do drop shipping?
A: Yes, we can help you ship the goods to any address you want. We will not put any catalogue or any document with our company info in it if you requested.
Q6: What is the shipping methods?
A: Usually by express, such as DHL, FedEx, TNT, UPS etc..
