Model | SFQ10-22A | SFQ15-22A | SFQ30-22A | SFQ40-22A |
Gas pressure | 0.7 bar | 0.7 bar | 0.7 bar | 1.5 bar |
Rated voltage | 220-240V~50Hz | 220-240V~50Hz | 220-240V~50Hz | 220-240V~50Hz |
Motor power input | 25W | 25w | 70w | 70w |
Max .gas consuption | 730 g/h | 1090 g/h | 2180 g/h | 2900g/h |
Max.heat input | 10KW | 15KW | 30KW | 40KW |
Hot air out put | 320 m³/h | 320 m³/h | 650 m³/h | 650 m³/h |
Net dimension | 379x187x302mm | 379x187x302mm | 475x220x350mm | 575x220x350mm |
Packing dimension | 390*215*290mm | 390*215*290mm | 490*250*355mm | 598*255*355mm |
QTY/40HQ | 2878 | 2878 | 1596 | 1228 |
N.W./G.W. | 3.4/4.6kg | 3.4/4.6kg | 5.3/6.9kg | 5.9/7.5kg |
Degree of electrical protection | IPX4 | IPX4 | IPX4 | IPX4 |
