Geiger Muller Tube Glass case J302 Hard Beta GM Detectors Nuclear radiation detection sensor GM tube
- Category: Other Analysis Instruments >>>
- Supplier: Henan Xinzhipu Import And Export Co. Ltd.
Share on (1600898358443):
Product Overview
Description
Product Description
Spec of (G-M) J302βγ Glass type Counting tube:
This tube is a tin oxide cathode with a coaxial cylindrical thin-walled structure (tube wall density of 50 ± 10cg/cm2) and a pulse
applied halogen tube. It can detect hard β and γ ray within 0.2R/h～5cGy/h in the surrounding temperature range of -40 ° C to 55 °
C.
Dimensions
1.Outside Diameter: 7.5±0.1mm
2.Maxium Length: 65±3mm
3.Material of outer case: Glass
The main parameters
1. Initial voltage(volts): 280~320V
2. Recommended operating voltage(volts): 390±10V
3. Volt-ampere characteristic slope: 1.25%/V
4. Discharge Voltage (Limiting): ＞550V
5. Output Current (Under 5 cGy/h irradiation): about 20µA
6. Minimum overload dose rate: 15 cGy/h
7. Operating temperature range (℃): -40℃~+55℃
8. Count Life (Under 5mr/h irradiation): 150 hours
9. Detecting: Gamma and hard Beta
Conditions of usage:
1. The counting tube shell should be kept highly clean. Minimize surface contamination as much as possible, otherwise it will
reduce insulation resistance
2. All the data of the Tube are all measured at the recommended working voltage, so users should keep them at the recommended
working voltage to obtain the given characteristic parameters
3. Please keep the output lead short and handle it carefully at the installing process.
This tube is a tin oxide cathode with a coaxial cylindrical thin-walled structure (tube wall density of 50 ± 10cg/cm2) and a pulse
applied halogen tube. It can detect hard β and γ ray within 0.2R/h～5cGy/h in the surrounding temperature range of -40 ° C to 55 °
C.
Dimensions
1.Outside Diameter: 7.5±0.1mm
2.Maxium Length: 65±3mm
3.Material of outer case: Glass
The main parameters
1. Initial voltage(volts): 280~320V
2. Recommended operating voltage(volts): 390±10V
3. Volt-ampere characteristic slope: 1.25%/V
4. Discharge Voltage (Limiting): ＞550V
5. Output Current (Under 5 cGy/h irradiation): about 20µA
6. Minimum overload dose rate: 15 cGy/h
7. Operating temperature range (℃): -40℃~+55℃
8. Count Life (Under 5mr/h irradiation): 150 hours
9. Detecting: Gamma and hard Beta
Conditions of usage:
1. The counting tube shell should be kept highly clean. Minimize surface contamination as much as possible, otherwise it will
reduce insulation resistance
2. All the data of the Tube are all measured at the recommended working voltage, so users should keep them at the recommended
working voltage to obtain the given characteristic parameters
3. Please keep the output lead short and handle it carefully at the installing process.
Specification
item | value |
Warranty | 1 YEAR |
Customized support | OEM, ODM |
Place of Origin | China |
Henan | |
Brand Name | XINZHIPU |
Model Number | J302 |
