Original High Performance R940 3U Server Storage Ram Nas Rack Server
- Category: >>>
- Supplier: Beijing Xinyuan Huizhi Technology Co. Ltd.
Share on (1600902883451):
Product Overview
Description
Product Paramenters
PowerEdge R940
The PowerEdge R940 Scale-up powerhouse for mission critical workloadsThe scalable business architecture of the Dell EMC PowerEdge R940 can deliver the most mission critical workloads. With automatic workload tuning for many workloads, configuration is quick. Combined with up to 6TB of memory and 13 PCIe Gen 3 slots the R940 has all the resources to maximize application performance and scale for future demands.
Processor | Up to four 2nd Generation Intel® Xeon® Scalable processors, up to 28 cores |
Memory | 48 DDR4 DIMM slots, Supports RDIMM /LRDIMM, up to 2933MT/s, 6TB max Up to 12 NVDIMM, 384GB Max Supports registered ECC DDR4 DIMMs only |
Storage controllers | Internal controllers: PERC S140, H330, H740P Boot optimized Storage Subsystem External HBAs (RAID): H840 External HBAs (non-RAID): 12 Gbps SAS HBA |
Internal Boot | Boot Optimized Storage Subsystem (BOSS):HWRAID 2 x M.2 SSDs 240GB, 480GB Internal Dual SD Module |
Storage | Front drive bays: Up to 24 x 2.5” SAS/SATA (HDD/SSD) with up to 12 NVMe PCIe SSD, max 122TB |
Power supplies | Platinum 1100W, 1600W, 2000W, 2400W, 336- 380VDC 1100W, Gold 48VDC 1100W |
Dimensions | Chassis depth: 777.05 mm |
Embedded management | iDRAC9, iDRAC Direct, iDRAC RESTful with Redfish, Quick Sync 2 wireless module (optional) |
Bezel | Optional LCD Bezel or Security bezel |
OpenManage Software | OpenManage Enterprise OpenManage Mobile OpenManage Power Manager |
Integrations and connections | Integrations: Microsoft System Center VMware vCenter BMC Truesight Red Hat Ansible? Modules Connections: Nagios Core & Nagios XI Micro Focus Operations Manager I IBM Tivoli Netcool/OMNIbus |
Security | TPM 1.2/2.0, TCM 2.0 optional Cryptographically signed firmware Secure Boot System Lockdown (requires iDRAC Enterprise or Datacenter) Secure erase Silicon Root of Trust |
I/O & Ports | Network daughter card options 4x 1Gb, 4x 10Gb, 2x 10Gb+2x 1Gb, or 2x 25Gb Front ports: Video, 2 x USB 3.0, dedicated IDRAC Direct USB Rear ports: Video, serial, 2 x USB 3.0, dedicated iDRAC network port Video card: VGA Up to 13 x Gen3 slots, (3 x8 + 10 x16) |
Accelerator options | Up to three 300W or six 150W GPUs, or up to three double-width or four single-width FPGAs. See Dell.com/GPU for latest information. |
Supported operating systems | Canonical? Ubuntu? Server LTS Citrix? Hypervisor Microsoft Windows Server? LTSC with Hyper-V Oracle? Linux Red Hat? Enterprise Linux SUSE? Linux Enterprise Server VMware? ESXi For specifications and interoperability details, see Dell.com/OSsupport. |
I/O & Ports | Network daughter card options 4 x 1GbE or 2 x 10GbE + 2 x 1GbE or 4 x 10GbE or 2 x 25GbE Front ports: 1 x Dedicated iDRAC Direct Micro-USB, 2 x USB 2.0, 1 x USB 3.0 (optional), 1 x VGA Rear ports: 1 x Dedicated iDRAC network port, 1 x Serial, 2 x USB 3.0, 1 x VGA Video card: 2 x VGA Riser options with up to 8 PCIe Gen 3 slots, maximum of 4 x 16 slots |
Accelerator options | Up to three 300W or six 150W GPUs, or up to three double-width or four single-width FPGAs. |
Supported operating systems | Canonical® Ubuntu® Server LTS Citrix® Hypervisor Microsoft Windows Server® LTSC with Hyper-V Oracle® Linux Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi |
Products Description
Company Profile
Beijing Xinyuan Huizhi Technology Co., Ltd.
Beijing Xinyuan Huizhi Technology Co., Ltd. was established in 2021, headquartered in Beijing, covering an area of 2,000 square meters. It is a professional company engaged in DE LL, Lenovo, inspur, HPE server and storage sales and service, with more than 100 channel sales and after-sales service staff. We have set up branches in Shanghai, Guangzhou, Shenzhen, Zhengzhou, Jinan, Nanning and Hohhot to provide IT products and technical services to customers worldwide. Our existing customers are located in Asia, Europe, Africa, South America and other countries and regions. We also provide various information solutions for government agencies, education, enterprises, finance, post and telecommunications, military, medical and other industries. We are committed to strict quality control and attentive customer service. Our experienced staff is always available to discuss your requirements to ensure complete customer satisfaction. We also welcome OEM and ODM orders. Based on our core philosophy of customer-centricity and customer-orientation, we provide customized solutions for our customers. We have accumulated extensive industry experience in requirements analysis, technical demonstration, equipment selection, network implementation, quality assurance, operation and maintenance, and service support. Whether you are selecting a current product from our catalog or seeking engineering assistance for your application, you can discuss your procurement needs with our customer service center.
