3HP ZB21KQE TFD R449a Open type cold room copeland compressor air cooled condensing unit

Product Overview

Description

Features

* Compact and sophisticated outlook

* Fully assembled and ready to be installed to save on assembly and applied cost

* Wide operating range

   - HT and MT from -20℃ to +5℃ evaporating temperature

  - Same unit for either MT or HT cold room application

  - Reduce inventory for distributors and contractors

*  Best-in-class scroll compressor efficiency and reliability

   - Up to 30% annual electrical savings from COP improvement as compared with reciprocating systems.

   - 70% fewer moving parts than reciprocating compressor

   - Superior liquid handling



*  Suit for R404a and R407F refrigerant.





Copeland ZB scroll compressor for Medium and low temperature

Open type                     R404a,R407F

Nominal data

Model	HP	Compressor	Voltage	Cooling capacity(W) at R404a					Axial Fans	Dimensions			Noisy	Connection
				Evaporating temperature(°C)
			(V-Ph-Hz)	-15	-10	-5	0	5	N°x Diameter	L	W	H	10m(db)	Inlet	Outlet
LKPG200	2	ZB15KQE-PFJ	220-1-50	2400	2950	3600	4300	5150	1 x 400	680	610	570	33	3/4"	3/8"
LKPG200S	2	ZB15KQE-TFD	380-3-50	2400	2950	3600	4300	5150	1 x 400	680	610	570	33	3/4"	3/8"
LKPG250	2.5	ZB19KQE-PFJ	220-1-50	3150	3800	4600	5450	6500	2 x 350	960	680	470	33	3/4"	3/8"
LKPG250S	2.5	ZB19KQE-TFD	380-3-50	3150	3800	4600	5450	6500	2 x 350	960	680	470	33	3/4"	3/8"
LKPG300	3	ZB21KQE-PFJ	220-1-50	3750	4550	5500	6550	7750	2 x 350	960	680	470	39	3/4"	3/8"
LKPG300S	3	ZB21KQE-TFD	380-3-50	3750	4550	5500	6550	7750	2 x 350	960	680	470	39	3/4"	3/8"
LKPG350	3.5	ZB26KQE-PFJ	220-1-50	4400	5350	6400	7650	9100	2 x 350	960	680	520	42	3/4"	1/2"
LKPG350S	3.5	ZB26KQE-TFD	380-3-50	4400	5350	6400	7650	9100	2 x 350	960	680	520	42	3/4"	1/2"
LKPG400S	4	ZB29KQE-TFD	380-3-50	5100	6200	7450	8900	10550	2 x 350	960	680	520	42	7/8"	1/2"
LKPG500S	5	ZB38KQE-TFD	380-3-50	6450	7800	9400	11200	13300	2 x 400	1060	680	730	43	7/8"	1/2"
LKPG600S	6	ZB45KQE-TFD	380-3-50	7550	9150	11000	13100	15550	2 x 400	1300	750	770	43	7/8"	1/2"
LKPG700S	7	ZB48KQE-TFD	380-3-50	8300	10050	12050	14400	17100	2 x 400	1300	800	970	43	7/8"	1/2"
LKPG800S	8	ZB58KQE-TFD	380-3-50	9100	11500	14150	17100	20400	2 x 450	1300	850	1170	55	1-1/8"	5/8"
LKPG1000S	10	ZB76KQE-TFD	380-3-50	13200	15700	18700	22200	26400	4 x 400	1300	850	1420	60	1-1/8"	5/8"
LKPG1300S	13	ZB95KQE-TFD	380-3-50	16100	19300	23000	27400	32500	4 x 400	1300	850	1520	60	1-3/8"	7/8"
LKPG1500S	15	ZB114KQE-TFD	380-3-50	19500	23500	28200	33500	40000	4 x 450	1365	850	1520	60	1-3/8"	7/8"
TEST CONDITION: Condensing Temperature: 50°C
