YB28T W Водонепроницаемые электрические часы светодиодные ночники Автомобильные электронные часы для автомобиля, электромобиля
- Category: >>>
- Supplier: Guangzhou Pinwo Electronic Technology Co. Ltd.
Share on (1600907345352):
Product Overview
Description
Specification:
Measurement range: 0-100V
Display mode: 00.00-99.99-100.0
Working voltage: DC 4-30V
Recommended working voltage: 5V / 12V
Power consumption: <=20mA
Refresh speed: 3 times /S
Test accuracy: 0.3% (maximum error = range X0.003)
Internal resistance of watch: 400K
Dimension: 60*29*21.5mm
Installation: 57.8*26mm
Display window size: 49*18mm 4 digit
Display color: red
Option color: if you need blue or green color, please contact our sales manager
Package includes:1 x Voltmeter
More Option Models:
There are several different models of voltmeter for choosing, you can choose the Amp range and color, please contact our sales manager for quotation.
As Following :Measurement range: 0-10V
Display mode: 0.000-9.999
Working voltage: DC 4-30V
Recommended working voltage: 5V / 12V
Power consumption: <=20mA
Refresh speed: 3 times /S
Test accuracy: 0.3% (maximum error = range X0.003)
Internal resistance of watch: 50K
Dimension: 60*29*21.5mm
Installation: 57.8*26mm
Display window size: 49*18mm 4 digit
Display color: Red / Green / Blue Optional
(2) Specification:
Measurement range: 0-30V
Display mode: 0.000-30.00
Working voltage: DC 4-30V
Recommended working voltage: 5V / 12V
Power consumption: <=20mA
Refresh speed: 3 times /S
Test accuracy: 0.3% (maximum error = range X0.003)
Internal resistance of watch: 130K
Dimension: 60*29*21.5mm
Installation: 57.8*26mm
Display window size: 49*18mm 4 digit
Display color: Red / Green / Blue Optional
(3) Specification:
Measurement range: 3.5-30V
Display mode: 03.50-30.00
Working voltage: DC 4-30V
Recommended working voltage: 5V / 12V
Power consumption: <=20mA
Refresh speed: 3 times /S
Test accuracy: 0.3% (maximum error = range X0.003)
Dimension: 60*29*21.5mm
Installation: 57.8*26mm
Display window size: 49*18mm 4 digit
Display color: Red / Green / Blue Optional
(4) Specification:
Measurement range: 0-50V
Display mode: 0.00-50.00
Working voltage: DC 4-30V
Recommended working voltage: 5V / 12V
Power consumption: <=20mA
Refresh speed: 3 times /S
Test accuracy: 0.3% (maximum error = range X0.003)
Internal resistance of watch: 130K
Dimension: 60*29*21.5mm
Installation: 57.8*26mm
Display window size: 49*18mm 4 digit
Display color: Red / Green / Blue Optional
(5) Specification:
Measurement range: 0-100V
Display mode: 00.00-99.99-100.0
Working voltage: DC 4-30V
Recommended working voltage: 5V / 12V
Power consumption: <=20mA
Refresh speed: 3 times /S
Test accuracy: 0.3% (maximum error = range X0.003)
Internal resistance of watch: 400K
Dimension: 60*29*21.5mm
Installation: 57.8*26mm
Display window size: 49*18mm 4 digit
Display color: Red / Green / Blue Optional
Package includes:1 x Voltmeter
