CEEG Factory 5.5KW 5.5KVA MPPT 220VAC 48V 5500W Single/Three Phase On Grid Solar inverter
CEEG Factory 5.5KW 5.5KVA MPPT 220VAC 48V 5500W Single/Three Phase On Grid Solar inverter
CEEG Factory 5.5KW 5.5KVA MPPT 220VAC 48V 5500W Single/Three Phase On Grid Solar inverter
CEEG Factory 5.5KW 5.5KVA MPPT 220VAC 48V 5500W Single/Three Phase On Grid Solar inverter
CEEG Factory 5.5KW 5.5KVA MPPT 220VAC 48V 5500W Single/Three Phase On Grid Solar inverter
CEEG Factory 5.5KW 5.5KVA MPPT 220VAC 48V 5500W Single/Three Phase On Grid Solar inverter
CEEG Factory 5.5KW 5.5KVA MPPT 220VAC 48V 5500W Single/Three Phase On Grid Solar inverter

CEEG Factory 5.5KW 5.5KVA MPPT 220VAC 48V 5500W Single/Three Phase On Grid Solar inverter

Share on (1600907349976):


Price:$740.00 - $780.00

Quantity:


Product Overview

Description



Product Description




Specification


Model
CHCI-3.6K-5.12kWh
CHCI-3.6K-10.24kWh
CHCI-5.0K-5.12kWh
CHCI-5.0K-10.24kWh
CHCI-6.0K-5.12kWh
CHCI-6.0K-10.24kWh
PV Input
Absolute max Voltage (V)
600
MPPT Voltage Range (V)
100-550
Max. DC Input Power (W)
4800
6650
8000
Start-up Voltage (V)
90
Rated Operating Voltage (V
360
Max. Input Current (A)
12.5/12.5
Isc PV (A)
18/18
NO. of MPP Trackers
2
NO. of Strings per MPP Tracker
Battery
Battery Capacity
LiFeP04 5.12kWh/10.24kWh
Nominal Battery Voltage (V)
204.8/409.6
Battery Voltage Range (V)
160...227.2/320...454.4
Max. Charge/Discharge Current (A)
25/25
AC Input/Output
Max. Apparent Power to Grid (VA)
3600
5000
6000
Rated Power (W)
3600
5000
6000
Max. Apparent Power from Grid (VA)
7200
10000
12000
Rated Voltage (V)
220/230/240
Rated Frequency (Hz)
50/60
Rated AC Current to Grid (A)
15.6
21.7
26.1
Rated AC Current from Grid (A)
31.2
43.4
52.2
Rated AC Current from Grid (A)
31.2
43.4
52.2
Displacement Power Factor
1（-0.8…+0.8 adjustable)
THDi
＜3%
EPS Output (With Battery)
Max. Output Power (W)
3600
5000
6000
Rated Apparent Power (VA)
4320
6000
7200
Rated Voltage (V)
230(±2%）
Norminal Frequency (Hz)
50/60(±0.2%）
Rated Output Current (a.c.A)
18.8
26.1
31.3
Switch time (ms)
＜10
THDv @Linear Load (%)
＜2
Efficiency
PV Max Eficiency (%)
97.6
PV Europe Efficiency (%)
97
PV Max. MPPT Efficiency (%)
99.9
Battery Discharge Efficiency (%)
96.7



Off-grid Inverter: Off-grid inverters are mainly used in off-grid solar systems or independent power systems, which do not depend on the public grid for power supply. It converts direct current (DC) electrical energy into alternating current (AC) electrical energy to meet the electrical demand in off-grid systems. Off-grid inverters are usually equipped with a battery storage system, which can store excess electrical energy in the battery for use at night or when energy is insufficient.

On-grid Inverter: On-grid inverters are mainly used in solar systems connected to the public grid. It converts the DC power
generated by solar panels into AC power that matches the frequency and voltage of the public grid and injects it into the public grid for other users. Grid-connected inverters have functions such as power limitation and power factor control to ensure a safe connection and coordinated operation with the grid.

Hybrid Inverter: A hybrid inverter combines the functions of an off-grid inverter and a grid-connected inverter. It can switch between off-grid mode and grid-connected mode and is suitable for solar energy systems that meet both off-grid and grid-connected requirements. Hybrid inverters can use solar power for power and feed excess power into the grid or store it in batteries when needed. Such inverters usually have functions such as battery management and charging control to achieve flexible power management and provision of backup power.


Company Profile








FAQ


1. who are we?
We are based in Jiangsu, China, start from 2017,sell to Northern Europe(59.00%),Africa(18.00%),South America(8.00%),Mid East(7.80%),South Asia(2.00%),North America(2.00%),Southeast Asia(1.90%),Central America(0.20%). There are total about 301-500 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
solar energy storage,solar energy panel,solar power inverter,solar hybrid inverter,solar battery

4. why should you buy from us not from other suppliers?
CEEG is a world-leading supplier of solar cells, modules and system solutions.

CEEG led Chinese PV companies to implement a feature project-"Whole Set of Key Technology Research and Demonstration Production
Line for the Industrialization of Low-Cost

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
