Finest PCB Assembly is a 18 years one-stop solution provide: *PCB manufacturing
*Components sourcing
*PCB assembly
*Firmware programming
*PCBA functional test
*Plastic/Metal case assembly
*Components sourcing
*PCB assembly
*Firmware programming
*PCBA functional test
*Plastic/Metal case assembly
We are professional aluminum PCB board manufacture in Shenzhen,with a plant area of 2500m' and 8 SMT production lines. Equipped with new imported Hanwha 471,481,482,automatic solder.paste printers, ten-temperature zone reflowsoldering, wave soldering and other high-techequipments like X-RAY for BGA board.,, offer not only original electronic component scourcing service and our own factory PCB board, but also offer PCBA assembly service , we have large amount of customers all over the world as below, if you have any request for PCB assembly, please let us know your detail, support original electronic components sourcing with cost-effective price. please send us your Bom lists for free quotation.
Products Show
Why choose Finest PCB Assembly? 1.More than 18 years experience of electronic manufacturing sevices for PCB making. 2.One stop service | PCB Manufacturing | Components sourcing and PCB assembly to help you easily achieve your electronic products. 3.more than 1000 customers working with us telecom, IOT, RF, smart control, security,medical,industrial,automotive, 3G / 4G / 5G products. 4.Reasonable and stable price: have established a strong global electronics components supply chain that help us get reasonable and stable pric 5.Quality assurance: more than 15 years experienced engineering team and quality control team to ensure all products come out under control. 6.Professional replace-solution: help customers source professional replace-solution to achieve faster, lower cost with high quality components purchasing agent servic
Certification | ISO 9001, ISO 13485, UL, ROHS |
Factory Area | 4000 Squre meter |
Year of Establishment | 2014 |
Capability | 3 SMT Lines for SMD components assembly 2 DIP Lines for THT components assembly 3 Assembly lines for Fully Products Assembly |
PCB Test | 100% Test |
PCB Test Equipments | 5 Flying Probe Test machines 6 Test Jig machines |
PCBA Test | 100% AOI Test |
Item | Aluminium Production Capability |
Base Material | Aluminium |
Layer | 1-2L |
Finished inner/outer cooper thickness | 1-2OZ |
Finished board thickness | 0.2-3.0mm |
Thermal Conductivity | 0.5/1/1.5/2W/m.K |
Minimum Size | 1500mm 1layer |
Controlled Impedance | ±5% |
Outline profile | Rout/ V-cut/ Bridge/ Stamp hole |
Surface treatment | HASL, HASL lead free, Immersion Gold, Immersion Tin, Immersion Silver, Hard gold, Flash gold, OSP… |
PCB Specification: | ||||||||||
PCB layers: | 1-24layers | |||||||||
PCB materials: | CEM1, CEM3, Teflon, Rogers, FR-4, High Tg FR-4, Aluminum Base, Halogen Free | |||||||||
PCB max. board size: | 620*1100mm (Custom) | |||||||||
PCB certificate: | RoHS Directive-Compliant | |||||||||
PCB Thickness: | 1.6 ±0.1mm | |||||||||
Out Layer Copper Thickness: | 0.5-5oz | |||||||||
Inner Layer Copper Thickness: | 0.5-4oz | |||||||||
PCB max. board thickness: | 6.0mm | |||||||||
Minimum Hole Size: | 0.20mm | |||||||||
Minimum Line Width/Space: | 3/3mil | |||||||||
Min. S/M Pitch: | 0.1mm(4mil) | |||||||||
Plate Thickness and Aperture Ratio : | 30:1 | |||||||||
Minimum Hole Copper: | 20µm | |||||||||
Hole Dia. Tolerance(PTH): | ±0.075mm(3mil) | |||||||||
Hole dia. Tolerance(NPTH): | ±0.05mm (2mil) | |||||||||
Hole Position Deviation: | ±0.05mm (2mil) | |||||||||
Outline Tolerance: | ±0.05mm (2mil) | |||||||||
PCB solder mask: | Black, white, yellow | |||||||||
PCB surface finished: | HASL Leadfree,Immersion ENIG,Chem Tin,Flash Gold,OSP,Gold finger,Peelable,Immersion Silver | |||||||||
Legend: | White | |||||||||
E-test: | 100% AOI, X-ray, Flying probe test. | |||||||||
Outline: | Rout and Score/V-cut | |||||||||
Inspection Standard: | IPC-A-610CCLASSII | |||||||||
Certificates: | UL (E503048),ISO9001/ISO14001/IATF16949 | |||||||||
Outgoing Reports: | Final Inspection, E-test, Solderability Test, Micro Section and More | |||||||||
PCBA Technical Capability | |
1. Assembly Type:: | FR4, FPC, Rigid-flex PCB, Metal base PCB. |
2. Assembly Specification: | Min size L50*W50mm; Max size: L510*460mm |
3. Assembly thickness: | Min thickness: 0.2mm; Max thickness: 3.0mm |
4. Components Specification | |
Components DIP: | 01005Chip/0.35 Pitch BGA |
Minimum device accurace: | +/-0.04mm |
Minimum footprint distance: | 0.3mm |
5. File format: | BOM list; PCB Gerber file: |
6. Test | |
IQC: | Incoming inspection |
IPQC: | Production inspection; first ICR test |
Visual QC: | Regularly quality inspection |
SPI test : | Automatic solder paste optical inspection |
AOI: | SMD component welding detection, components shortage & component polarity detection |
X-Ravd: | BGA test; QFN and other precision devices hidden PAD device inspection |
Function test: | Test function and performance according to customer's test procedures and steps |
7. Reworking: | BGA rework equipment |
8. Delivery Time | |
Normal delivery time: | 24 hours( fastest 12 hours quick-turn) |
Small production: | 72 hours( fastest 24 hours quick-turn) |
Medium production: | 5 working davs. |
9. Capacity: | SMT assembly 5 million point/day;plug-in & welding 300,000 point/day; 50-100 items/day |
10. Components Service | |
A full set of substitute materials: | Have a experience component procurement sourcing, management system, and provide cost-effective services for OEM projects |
Only SMT: | Do SMT and backhand welding according to components PCB boards provided by customers. |
Components purchasing: | Customers provide core components, and we provide components sourcing services. |
