Sanding Machine Sander for MDF / OSB / Particle Board / Chipboard / Plywood / HPL / Composite Material and Metal
- Category: >>>
- Supplier: Shenzhen Aucox Technology Co. Ltd.
Share on (1600909278600):
Product Overview
Description
Products Description
Woodworking Machinery Plywood Furniture Solid Wood Panel Calibrating Calibration Sander Wide Belt Sanding Machine
Woodworking sanding machine is a kind of commonly used woodworking machinery. It is a mechanical equipment that uses the cutting action of gravel to smooth the processing traces, burrs, and stains on the wood surface..
Model | R-RP630 | R-RP1000 | R-RP1300 |
sanding wood width | 2~630mm | 2~1000mm | 2~1300mm |
sanding wood thickness | 2~100mm | 2~100mm | 2~100mm |
sanding wood length | min 450mm | min 450mm | min 450mm |
first sanding speed | 20m/sec | 20m/sec | 20m/sec |
second sanding speed | 18m/sec | 18m/sec | 18m/sec |
transmission speed | 5~25m/min | 5~25m/min | 5~25m/min |
first sanding size | 650x1930mm | 1020x1930mm | 1320x2200mm |
second sanding size | 650x1930mm | 1020x1930mm | 1320x2200mm |
Motor power | 20.37KW | 27.87KW | 56.37KW |
first sanding motor | 11KW | 15KW | 30KW |
second sanding motor | 7.5KW | 11KW | 22KW |
transmission motor | 1.5kw | 1.5kw | 4kw |
working lift motor | 0.37KW | 0.37KW | 0.37KW |
working pressure | 0.55M pa | 0.55M pa | 0.55M pa |
pressure air working | 1.56m3/min | 1.56m3/min | 1.56m3/min |
control pressure | 0.09m3/min | 0.09m3/min | 0.09m3/min |
dust wind need | 25~30m/s | 25~30m/s | 25~30m/s |
overall size | 109x179x208cm | 149x178x208cm | 263x206x204cm |
weight | 1400kgs | 1800kgs | 3200kgs |
Details Images
Recommend Products
FAQ
Q1: What is the warranty for the machine?
For our woodworking machine, we have 18months warranty.
Q2:Can I choose the Plug?
Yes,we have 220V/440V/380V for your choice,and 1phase,3phase,50hz and 60hz
Q3.What is your lead time after i pay?
Normally,we have stock for the machine,only customized for voltage ,about 7days or 15days.
Q4:How long will i get the machine after i pay?
The machine will deliver by sea to your port.about 20~55days arrival.
Q5:Is it OK to print my logo on the product?
Yes.Please inform us formally before our production and confirm the design firstly for the mass production.
Q6:It is my first time to purchase goods from china,how do i do?
Do not worry,Aucox/Woodfung has 10years export experience to all over the world,
also has professional sales team,we also have agent in Russia,Algeria,Pakistan,Peru,Vietnam,etc.
Q7:How to pack the machine?
we use wooden box to packge the machine to protect them to be safe
Q8.I do not know chinese,will the operation panel in english or spanish or other?
Yes,all our machine are with Chinese and English,If you want only English or Spanish or other,
we also can customize to you,but lead time will be a little longer.
For our woodworking machine, we have 18months warranty.
Q2:Can I choose the Plug?
Yes,we have 220V/440V/380V for your choice,and 1phase,3phase,50hz and 60hz
Q3.What is your lead time after i pay?
Normally,we have stock for the machine,only customized for voltage ,about 7days or 15days.
Q4:How long will i get the machine after i pay?
The machine will deliver by sea to your port.about 20~55days arrival.
Q5:Is it OK to print my logo on the product?
Yes.Please inform us formally before our production and confirm the design firstly for the mass production.
Q6:It is my first time to purchase goods from china,how do i do?
Do not worry,Aucox/Woodfung has 10years export experience to all over the world,
also has professional sales team,we also have agent in Russia,Algeria,Pakistan,Peru,Vietnam,etc.
Q7:How to pack the machine?
we use wooden box to packge the machine to protect them to be safe
Q8.I do not know chinese,will the operation panel in english or spanish or other?
Yes,all our machine are with Chinese and English,If you want only English or Spanish or other,
we also can customize to you,but lead time will be a little longer.
Warranty
1. AUCOX Provide 15 months warranty for all customers.
2. During warranty, we provide free normal spare parts once machine has probem.
3. AUCOX will solve customer's machine problem within 24 hours from the time problem raised.
4. AUCOX has enough spare parts for machines.
5. When machine out of warranty, AUCOX still provide free technical support and spare parts charged to customers.
ATTENTION:all machines in the website is always improving,if there is a little changed,no care.it is not influence the
usage,better quality for always improvement.
2. During warranty, we provide free normal spare parts once machine has probem.
3. AUCOX will solve customer's machine problem within 24 hours from the time problem raised.
4. AUCOX has enough spare parts for machines.
5. When machine out of warranty, AUCOX still provide free technical support and spare parts charged to customers.
ATTENTION:all machines in the website is always improving,if there is a little changed,no care.it is not influence the
usage,better quality for always improvement.
