CX1100-0002 | Power supply units and I/O interfaces for CX1010/CX1020
One of four power supply modules can be selected for CX1010/CX1020 systems. The power supply of all other system components is
ensured via the internal PC/104 bus; no separate supply lines are required. However, the CX1100 components offer further important
characteristics that go beyond a pure power supply: an integrated NOVRAM enables the fail-safe storage of process data, an LC
display with two lines of 16 characters each is used for displaying system and user messages. The power supplies of the CX system
can be changed in the field.
In addition to the power supply and the three basic functions display, navigation switch and NOVRAM, the CX1100-0002 also offers
the I/O connection for Bus Terminals (KLxxxx). The Bus Terminal connection option creates a controller with a highly variable,
expandable I/O level with a wide range of signals. The I/O data are stored in a DPRAM that is accessible to the CPU via the system
bus.


item
value
Brand Name
Beckhoff
Model Number
CX1100-0002
Relative humidity
95 %, no condensation
Power supply
24 V DC (-15 %/+20 %)
E-bus connection
–
K-bus connection
yes (adapter terminal)
IP-Link connection
–
Current supply E-bus
–
Current supply K-bus
up to max. 1.75 A
Type of connection
spring-loaded technique (adapter terminal)
NOVRAM
8 kbytes
Display
FSTN display 2 lines x 16 characters of text, illuminated
I/O-DPRAM
4 kbytes
Diagnostics LED
1 x PWR, 1 x I/O Run, 1 x I/O Err
Max. power consumption
3.5 W
Dimensions (W x H x D)
40 mm x 100 mm x 91 mm
Weight
approx. 250 g
Operating/storage temperature
0…+55 °C/-25…+85 °C
Relative humidity
95 %, no condensation
Vibration/shock resistance
conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission
conforms to EN 61000-6-2/EN 61000-6-4
Protection rating
IP20
Approvals/markings
CE, UL
