KEFAI 110V Full Automatic 4 Head Tomato Paste Peanut Butter Liquid Paste Piston Filling And Capping Machine Bottle Filling Line
- Category: >>>
- Supplier: Wuhan Kefai Innovation Machinery Co. Ltd.
Share on (1600909788442):
Product Overview
Description
Product Description
Description
The fully automatic filling, capping and labeling machine is liquid filling line which is designed to fill bottles and jars with products of various liquid, range from water thin liquids to thick creams. Widely used in cosmetic, food, oil and other industries. These inline piston filling machines can be option with different fill heads for meet different production capacity,variable speed drive conveyor, adjustable stainless steel frame, easy to operate PLC control panel.Features
1, 304 Stainless steel heavy duty stainless steel welded C frame.
2, All parts contact with material is SUS316, sanitary, Teflon, Viton and hoses per your requirements.
3, Real time adjustability.
4, No bottle no fill, PLC control
5, Accurate filling volume, within ±1% and a total bottle counter.
6, Easy to maintain, no special tools are required.
7, Special seals or hoses by order.
8, Blocked nozzles for products that tend to string and drip.
9, Diving nozzles for bottom up filling of foaming products.
10, Bottle mouth localizer.
2, All parts contact with material is SUS316, sanitary, Teflon, Viton and hoses per your requirements.
3, Real time adjustability.
4, No bottle no fill, PLC control
5, Accurate filling volume, within ±1% and a total bottle counter.
6, Easy to maintain, no special tools are required.
7, Special seals or hoses by order.
8, Blocked nozzles for products that tend to string and drip.
9, Diving nozzles for bottom up filling of foaming products.
10, Bottle mouth localizer.
11, The filling head can also be added to suit your special need.
Application
KEFAI Automatic Liquids Bottle Filling Capping Labeling Machine is suitable for filling all kinds of liquid and psate, such as juice, milk, tomato sauce, peanut sauce, cream, alcohol, glue etc,
Product Paramenters
Heads | 2 | 4 | 6 | 8 | 10 | 12 | 16 | ||||||
Range（ml） | 100-500,100-1000,1000-5000 | ||||||||||||
Capacity（bpm）base on 500ml | 12-14 | 24-28 | 36-42 | 48-56 | 60-70 | 70-80 | 80-100 | ||||||
Air Pressure（mpa） | 0.6 | ||||||||||||
Accuracy（%） | ±0.1-0.3 | ||||||||||||
Power | 220VAC SINGLE PHASE 1500W | 220VAC SINGLE PHASE 3000W | |||||||||||
Details of machine
For More Details,
Please Send An Inquiry To Get It.
