Phenix H236 A 1600x LED 1W Illumination Veterinary Medical Trinocular Biological Microscope for Live Blood Analysis
- Category: >>>
- Supplier: Jiangxi Phenix Optical Technology Co. Ltd.
Share on (1600909887225):
Product Overview
Description
Phenix H236-A 1600x LED 1W Illumination Veterinary Medical Trinocular Biological Microscope for Live Blood Analysis
Product Description
Hollow series biological microscope,using ergonomic design,smooth whole line,beautiful appearance,compact structure.Easy to observe and use a long observation faigue.Built-in handle for easy pick up.Hollow series biological microscopes are available universities,teaching and researh biology,pathology,bacteriology and many other healh units,laboratories and research institutes and clinical trials used in the analysis.
| Part Name | Specification | H236-A | H226-A |
| 40-1600X monocular quadruble abbe double ring LED 1W | 40-1600X binocular quadruble 195 abbe double ring LED 1W | ||
| Viewing head | Monocular,45° inclined,360° rotatable | ||
| Monocular TV,45° inclined,360° rotatable | |||
| Compensation binocular head,30° inclined, interpupillary distance 48-75mm. | √ | ||
| Compensation trinocular head,30° inclined, interpupillary distance 48-75mm. | √ | ||
| Eyepiece | WF10X/18mm | √ | √ |
| WF16X/15mm | √ | √ | |
| Objective 195 Achromatic | 4X,10X,40X(S),100X(SO) | √ | √ |
| Nosepieces | Quadruble | √ | √ |
| Focusing system | Coaxial coarse&fine focusing knob,coarse focusing range 22mm,fine focusing graduation 0.002mm | √ | √ |
| Working Stage | Double layer mechanical stage,size 120*115mm,76*40mm,with Abbe Condenser | √ | √ |
| Condenser | Abbe condenser N.A.=1.25,with iris diaphragm,lifting rings. | √ | √ |
| Illumination | Critical illumination | √ | √ |
| Lamp | Reflector(As an attachment support) | √ | √ |
| LED 1W,brightness adjustable,rechargable | √ | √ | |
| Dimming | Digital circui,stepless adjustment light,no screen flashing | √ | √ |
| Power | LED switch power,input AC 90V-240V.wide voltage. putout:DC 5V/2A | √ | √ |
| Packing | Foam+carton | √ | √ |
| Other | 1XC mount | √ |
Detailed Images
