Factory Hadfield High Wear Resistant Steel Castings High Manganese Steel Scrap Steel Plate Price
- Category: >>>
- Supplier: Shandong Tianyu Metal Products Co. Ltd.
Share on (1600910101723):
Product Overview
Description
Mn13 X120Mn12 high manganese steel is the best choice among wear-resistant materials that can resist strong impact and high pressure material wear. It has the work hardening characteristics that other wear-resistant materials cannot match. Under the action of large impact load or large contact stress, the steel plate surface will produce work hardening, and the surface hardness will rapidly increase from HB200 to HB500, thus producing a high wear-resistant surface layer.
There are two main characteristics of Mn13 X120Mn12 high manganese steel: one is that the greater the external impact, the higher the wear resistance of its surface layer; the other is that with the gradual wear of the surface hardening layer, new work hardening layer will continue to form. Mn13 X120Mn12 rolled steel plate has excellent wear resistance to strong impact wear and high stress wear, and will not break during use. It also has easy mechanical processing properties such as cutting, welding, bending, etc.High manganese steel is a special property, which is suitable for making wear-resistant components with high impact materials for a long time. It has been widely used in metallurgy, mining, building materials, railway, power, coal, cement and other mechanical equipment
Place of Origin | China |
Product name | High manganese steel plate |
advantage | wear resistant |
MOQ | 1 kg |
application | metallurgy, mining, building materials, railway |
Packing | Standard |
Keyword | High manganese wear resistant steel plate |
Size | Customized |
chemical composition | ||||||||||
Grade | C | Si | P | S | Mn | |||||
Mn13 | 0.90~1.20 | 0.30~0.80 | ≤0.035 | ≤0.030 | 11.00~14.00 | |||||
Mechanical property | ||||||||||||
Grade | Elongation | tensile strength | 20°C Impact Resistance | Initial Hardness(HB) | Hardness after Hardened(HB) | 180°cold Bending Test | ||||||
Mn13 | ≥40% | ≥800MPa | ak≥90（J） | 200-250 | >300 | Qualified | ||||||
Standard | Grade |
GB | Mn13 |
ASTM | A128 |
JIS | SCMnH11 |
AFNOR | Z120Mn12 |
DIN | X120Mn12、 1.3401 |
ГOCT | 116Г13Ю |
1. High wear resistance: the wear resistance is more than 15-20 times that of ordinary steel plates, 5-10 times that of low-alloy steel plates, and 2-5 times that of high-chromium cast iron.
2. Better impact performance: the wear-resistant layer resists the wear of the wear medium, and the substrate bears the load of the medium
3. Better heat resistance: The alloy wear-resistant layer is recommended to be used under ≤600℃. If vanadium, molybdenum and other alloys are added to the alloy wear-resistant layer, it can withstand high temperature wear of ≤800℃.
4. Good corrosion resistance: The alloy layer of the wear-resistant composite steel plate contains a high percentage of metallic chromium, so it has certain rust and corrosion resistance.
5. Good processing performance: wear-resistant steel plate can be cut, bent or crimped, welded and punched, and can be processed into various parts
2. Better impact performance: the wear-resistant layer resists the wear of the wear medium, and the substrate bears the load of the medium
3. Better heat resistance: The alloy wear-resistant layer is recommended to be used under ≤600℃. If vanadium, molybdenum and other alloys are added to the alloy wear-resistant layer, it can withstand high temperature wear of ≤800℃.
4. Good corrosion resistance: The alloy layer of the wear-resistant composite steel plate contains a high percentage of metallic chromium, so it has certain rust and corrosion resistance.
5. Good processing performance: wear-resistant steel plate can be cut, bent or crimped, welded and punched, and can be processed into various parts
1.Q: Are you a factory or trading company?
A:We are manufacture factory. And you are welcomed to visit us for inspection. The quality control flow will show you our professional. Also you will enjoy the best price and competitive price.
2.Q: How long is your delivery time?
A:Generally it is within 2-30 days.
3.Q: How do you guarantee the quality of the products?
A:Strict product quality control, quality makes the future.This is the tenet of our factory. Each product from our factory has strict testing procedures, and must be 100% quality before delivery.
4.Q: what can you buy from us?
A: Bulletproof steel plate,Wear resistant steel plate,High strength steel plate,Alloy steel plate，Stainless steel，Safety protection product .etc
5.Q: Can I get some samples?
A: We are glad to provide free samples to you, but we do not offer the freight.
