Japan toyota style diesel/gasoline/lpg forklift truck 2.5 ton 3ton 3m 4m 5m 6m triplex mast

Model

-

CPC30

Rated capacity

kg

3000

Load center

mm

500

Max.lifting height

mm

3000-7000mm

Free lifting height

mm

100

Fork size L*W*H

mm

1070*125*50

Mast tilting angle forward/backward

°

6/12

Min. turning radius

mm

2450

Min. ground clearance (mast)

mm

135

Overhead guard height

mm

2160

Height from seat to overhead guard

mm

1005

Max. traveling speed (loaded)

km/h

20

Max. lifting speed (loaded/unloaded)

mm/s

480/560

Max. traction/gradeability (loaded)

kN/°

20/20

Min. right angle stacking aisle width

mm

4280

Overall length (without fork)

mm

2700

Overall width

mm

1225

Mast lowered height

mm

2060

Mast extended height

mm

3650

Tyre(front)

-

28*9-15-12PR

Tyre(rear)

-

6.50-10-10PR

Wheelbase

mm

1700

Tread(front/rear)

mm

1000/970

Curb weight(none-load)

kg

4560

Battery(voltage/capacity)

V/Ah

12/80

Engine(model)

-

C490

Engine(rated power)

kW/r.p.m

36.8/2500

Engine(rated torque)

Nm/r.p.m

156/1700

Engine(cylinder amount)

-

4

Engine(bore*stroke)

mm

90*105

Engine(displacement)

L

2.54

Fuel tank capacity

L

70

Transmission

-

Automatic/Mechanical

Working pressure

MPa

17.5
