8 100Mbps 2 Gigabit Desktop OEM Ethernet Switch AI Port Automatic Restart Power Supply Adapter 250m Distance Output PoE Sw
- Category: >>>
- Supplier: Shenzhen Qifang Industrial Development Co. Ltd.
Share on (1600910187302):
Product Overview
Description
Products Description
Product Name | 8 10/100Mbps+2 Gigabit PoE Switch |
Model | QF308EP-2G |
Function | PoE |
Package | 1 pcs/ box. 20 boxes/carton |
8 10/100Mbps+2 Gigabit PoE Switch
This new 10 ports PoE switch provides power and data from a single point, using Power over Ethernet(PoE) over a single Cat5 cable. It can be used for any 10/100Mbps link PoE port with 2 more gigabit Uplink and supply industry-standard IEEE 802.3af /at power. Advanced auto-sensing algorithm gives power to IEEE802.3af/at end devices,In addition,the PoE switch automatically determines PoE requirements, speed, duplex. Easy to operate and reliable. It also provides a switch button to extend the Ethernet transmission distance of 8 POE Ethernet ports up to 250m which make the installation more flexible.
This PoE switch is ideal for powering PoE devices such as IP cameras,WLAN access points, IP phones, office access control systems, and other PD devices and offers a line of high quality products that provide a total solution for ethernet application in different environments.
This PoE switch is ideal for powering PoE devices such as IP cameras,WLAN access points, IP phones, office access control systems, and other PD devices and offers a line of high quality products that provide a total solution for ethernet application in different environments.
Features
Features
● Fully IEEE802.3af/at standard compliant.
● Support PoE power up to 15.4/30W for each PoE ports.
● Support 250m PoE distance transmission
● Plug & Play. No configuration required.
● Reliable and great value.
Product Paramenters
Model | QF308EP-2G | ||||
Ports description | POE port | 1-8ports:10/100M Auto-Negotiation RJ45 | |||
UPlink port | 9-10port: Gigabit Auto-Negotiation RJ45 | ||||
POE power | MAX POE output | 25.5W | |||
Total power consumption | 96W | ||||
POE port priority | Support | ||||
LED indicators | PWR(Power indicator light)、 POE(POE indicator)、Link/Act(Link / activity indicator) | ||||
Proccessing types | Store and forward | ||||
Transmission model | IEEE802.3X full-duplex and Backpressure half-duplex | ||||
Performance specification | Backplane bandwidth | 5.6Gbps | |||
Packet forwarding rate | 0.72Mpps | ||||
MAC address | 1k | ||||
Network standard | IEEE802.3i 10 BASE-T IEEE802.3u 100 BASE-TX IEEE802.3x Flow Control IEEE802.3af Power over Ethernet IEEE802.3at Power over Ethernet IEEE802.3az EEE | ||||
Input volatage | AC220V. 50/60Hz, total 96W power | ||||
Weight | 1KG | ||||
Dimension | 230mm*190mm*70mm(W×D×H) | ||||
Cable requirements | UTP cat5 or abover | ||||
Environment specification | Operating temperature: -10℃~45℃，operating humidity: 10％~90％ | ||||
Storage temperature: -20℃~70℃，storage humidity: 5％~95％ | |||||
Certifications
Product Plug and Transport
1. Input: AC100-240V 50/60Hz
2.Support different plugs according to customer needs
1. Sample orders: Usually shipped by international express delivery
2. Bulk orders: Arrange freight according to the customer's designated freight forwarder
