Gooxi 1U 4 bays EEB 12\
- Category: Computer Cases & Towers >>>
- Supplier: Shenzhen,Gooxi,Information,Security,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
● 1U Rackmount server chassis series with 640mm depth
● Serverboard supports up to standard EEB 12"x13", backward supports to CEB and below
● Supports 1x full-height full-length PCIe cards
● High-performance 5x4028 cooling fans with anti-vibration mechanism and optional up to 6x4056 middle fans
● Smart system fan controlled by intelligent temperature managemant
● Supports 1U Single PSU or 1+1 Redundant PSU
● 12Gb/s SAS passive backplane with SGPIO, compatible with SAS and SATA HDDs
● Serverboard supports up to standard EEB 12"x13", backward supports to CEB and below
● Supports 1x full-height full-length PCIe cards
● Front 10x2.5" hot-swap HDDs
● High-performance 5x4028 cooling fans with anti-vibration mechanism and optional up to 6x4056 middle fans
● Smart system fan controlled by intelligent temperature managemant
● Supports 1U Single PSU or 1+1 Redundant PSU
● 12Gb/s SAS passive backplane with SGPIO, compatible with SAS and SATA HDDs
Product Paramenters
Chassis | Rackmount |
Form Factor | 1U |
Serverboard | EEB(12"x13"), CEB(12"x10.5"), ATX(12"x9.6") and micro ATX (9.6"x9.6") |
PSU Form Factor | 1U Single or 1+1 Redundant |
Backplane SGPIO | Supports |
HDD Backplane | 10-port 12Gb/s SAS passive backplane |
HDD Hot-swap | Supports SAS and SATA HDD |
Hot-swap Fans | N/A |
HDD Drive | Front 10x2.5" Hot-swap HDDs |
Other Drive Bay | N/A |
Cooling Fans | Default 5x4028 middle fans (Max. 6x4056 by option) |
Temperature Control | Supports system smart fan controlled by Serverboard |
Air Duct | Optional |
Expansion Slots | Default 1x full-height PCIe cards support |
Slide Rail | Optional |
Indicators | 2x USB2.0, 1x Power Switch, 1x Reset, 1x Power LED, 1x HDD LED, 2x LAN Indicators |
Tool-less | N/A |
Metal Thickness | 1mm SGCC |
Chassis Dimensions | 640*433*43.5mm (DxWxH) |
Net Weight | 7.3 KG |
Carton Dimensions | 902*591*183mm (DxWxH） |
Gross Weight | 9.7 KG |
Certification | CE, FCC, RoHS |
Company Profile
Gooxi, a prominent provider of server solutions in China, offers a comprehensive range of hardware and software products. With a strong focus on research and development, Gooxi stands out by integrating R&D, production, sales, and service. Our product portfolio includes server and storage platforms, barebone system, motherboard, chassis, accessories, etc., catering to various sectors such as cloud computing and artificial intelligence.
Gooxi's independent R&D center in Shenzhen comprises a team of nearly 200 experts, covering all aspects of server development, from motherboard design to AI algorithms. We customize products based on customer needs and continuously invest in R&D to enhance their capabilities.
Gooxi's manufacturing system in Dongguan spans over 15,000 square meters, housing 12 production lines and advanced production platforms. With an annual output of over 300,000 servers, Gooxi has gained trust as a supplier for listed companies and large enterprises.
Gooxi has a global marketing service system. Headquartered in Shenzhen, it has established 4 major branches in Beijing, Dongguan, Shanghai and Hong Kong. It also has overseas business development departments, sales outlets, and cooperative dealers worldwide.
With about 10 years of experience, Gooxi remains committed to customer satisfaction and innovation, advancing in core technologies and obtaining many national intellectual property rights. Gooxi has made remarkable achievements in information innovation, and has established strategic partnerships with suppliers such as Intel, AMD, and Seagate.
Driven by integrity, collaboration, and innovation, Gooxi aims to be the world's top provider of server solutions.
Gooxi's independent R&D center in Shenzhen comprises a team of nearly 200 experts, covering all aspects of server development, from motherboard design to AI algorithms. We customize products based on customer needs and continuously invest in R&D to enhance their capabilities.
Gooxi's manufacturing system in Dongguan spans over 15,000 square meters, housing 12 production lines and advanced production platforms. With an annual output of over 300,000 servers, Gooxi has gained trust as a supplier for listed companies and large enterprises.
Gooxi has a global marketing service system. Headquartered in Shenzhen, it has established 4 major branches in Beijing, Dongguan, Shanghai and Hong Kong. It also has overseas business development departments, sales outlets, and cooperative dealers worldwide.
With about 10 years of experience, Gooxi remains committed to customer satisfaction and innovation, advancing in core technologies and obtaining many national intellectual property rights. Gooxi has made remarkable achievements in information innovation, and has established strategic partnerships with suppliers such as Intel, AMD, and Seagate.
Driven by integrity, collaboration, and innovation, Gooxi aims to be the world's top provider of server solutions.
Qualification & Honor
Gooxi Corporation owns 250 patents:
108 patents of invention
79 utility models
31 outward appearance patents
32 software copyrights
108 patents of invention
79 utility models
31 outward appearance patents
32 software copyrights
