1kva 2kva 3kva 4kva 5kva 8000w Invert hybrid solar inverter off grid solar 12V To 220V Inverter
- Category: >>>
- Supplier: Changzhou Guangheng Photovoltaic Technology Co. Ltd.
Share on (1600910719947):
Product Overview
Description
1kva 2kva 3kva 4kva 5kva PWM hybrid solar inverter off grid solar inverter
Features of 24V/48VDC solar power inverter
1.Pure sine wave inverter
2.Built-in PWM solar charge controller
3.Selectable input voltage range for home appliances and personal computers.
4.Selectable charging current based on applications
5.Configurable AC/Solar input priority via LCD setting
6.Compatible to mains voltage or generator power
7.Auto restart while AC is recovering
8.Overload and short circuit protection
9.Smart battery charger design for optimized battery performance
10.Cold start function
11.Parallel operation with up to 4 units only available for MKS 4K/5K
2.Built-in PWM solar charge controller
3.Selectable input voltage range for home appliances and personal computers.
4.Selectable charging current based on applications
5.Configurable AC/Solar input priority via LCD setting
6.Compatible to mains voltage or generator power
7.Auto restart while AC is recovering
8.Overload and short circuit protection
9.Smart battery charger design for optimized battery performance
10.Cold start function
11.Parallel operation with up to 4 units only available for MKS 4K/5K
Product Parameter
Model NO. | GH1K | GH3K | GH5K | |||
Rated Power | 1000VA/800W | 3000VA/2400W | 5000VA/4000W | |||
INPUT | Phase&waveform | 230 VAC | ||||
Voltage selectable range (for Personal Computer) | 170~280 VAC | |||||
Voltage selectable range (for home appliance) | 90~280 VAC | |||||
Frequency range | 50Hz/60Hz (Auto sensing) | |||||
OUTPUT | AC voltage Regulation (Batt.Mode) | 230V AC ± 5% | ||||
Surge Power | 2000VA | 6000VA | 10000VA | |||
Efficiency (Peak) | 90% | 93% | ||||
Transfer time | 10ms (for personal computer),20ms (for home appliance) | |||||
Wave form | Pure sine wave | |||||
Battery& AC Charger | Battery voltage | 12VDC | 24VDC | 48VDC | ||
Floating charge Voltage | 13.5VDC | 27VDC | 54VDC | |||
Overcharge Protection | 15VDC | 30VDC | 60VDC | |||
Maximum Charge Current | 10A or 20A | 20A or30A | 10A/20A/30A/40A/50A/60A | |||
PV Input | Charge current | 50A | ||||
MPPT Range @ Operating Voltage (VDC) | 50VDC | 60VDC | 105VDC | |||
Standy powr consumption | 1W | 2W | 2W | |||
Physical | Dimension, D×W×H (mm) | 305x300x110 | 305x272x100 | 413x295x120 | ||
Net Weight (Kgs) | 4.5 | 6.9 | 9.8 | |||
Environmental | Humidity | 5%~95% Relative Humidity (Non-condensing) | ||||
Operation Temperature | 0℃~55℃ | |||||
Storage Temperature | -15℃~60℃ | |||||
Product Link Skretch
Certifications
Project Cases
Company Profile
Changzhou Guangheng Photovoltaic Technology Co., LTD.,
founded in 2017, located in Changzhou City, Jiangsu Province, is committed to distributed photovoltaic power generation system equipment, wafers, photovoltaic modules, photovoltaic equipment, packaging materials sales.
We also committed to technology research and development, technical consulting, technical services, technology transfer in the field of photovoltaic; Import and export business of various kinds of commodities and technologies, as well as installation, testing and maintenance of solar photovoltaic power system .
We specialize in solar products for more than 10 years, selling original Tier 1 brand solar panels, with annual sales of more than 5GW.
We are one of the largest PV suppliers in China and ranked in the top 3 in the industry.Our warehouse area is over 50,000㎡, and we have sufficient stock for quick delivery.
We also committed to technology research and development, technical consulting, technical services, technology transfer in the field of photovoltaic; Import and export business of various kinds of commodities and technologies, as well as installation, testing and maintenance of solar photovoltaic power system .
We specialize in solar products for more than 10 years, selling original Tier 1 brand solar panels, with annual sales of more than 5GW.
We are one of the largest PV suppliers in China and ranked in the top 3 in the industry.Our warehouse area is over 50,000㎡, and we have sufficient stock for quick delivery.
Product packaging
FAQ
Q:Are you a factory or a trading company? |
A:We are a professional Solar Panels Manufacturer in China |
Q:How can we guarantee the products quality? |
A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments; |
Q:What products we can supply you? |
A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc |
Q:Where is your Manufacturer located? How can I visit there? |
A:Our factory located in 501, Building 1, No. 600, Tongjiang Middle Road, Changzhou City, Jiangsu Province,China |
Q:Can the products pricing be cheaper? |
A:Of course, you will be offered a a very good discount with large quantities. |
Q: Can print our company‘s logo on the pv panels? |
A:Yes! And we accept the OEM&ODM orders. |
