Factory Price GB GCr15 JIS SUJ2 EN31 535A99 DIN 52100 1.3505 Cold Drawn Alloy Structural Steel Product

Factory Price GB GCr15 JIS SUJ2 EN31 535A99 DIN 52100 1.3505 Cold Drawn Alloy Structural Steel Product

1: DIN 1.3505 steel introduction

     1.3505 bearing steel is a kind of high quality alloy bearing steel, which belongs to high carbon and low alloy steel containing chromium. 1.3505 Oil quench and temper quench hardness 28-34 HRc. DIN W-NR 1.3505 Steel annealed delivery hardened less than 250 HB.

2: DIN 1.3505 steel equivalent

3: DIN 1.3505 steel chemical composition

4: DIN 1.3505 steel mechanical properties

    The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.

5: DIN 1.3505 steel overviews

6. Heat Treatment

     Annealing : Slowly heat to 872° C (1600° F) and then slowly cool to reduce cold working or machining stresses. Different annealing methods will give different hardness. 1.3505 Bearing steel will obtain hardness MAX 248 HB.

     Quenching : Heat slowly to 816° C (1500° F) and quench in oil to obtain a hardness of 62 – 66 HRc. High temperature tempering: 650-700℃, air cooled, hardness 22-30HRC. Low temperature tempering: 150-170℃, hardness: 61-66 HRC.

7: Delivery condition
    For hot forged  bar, usually the delivery condition is hot forged, annealed/QT, rough turned/Black surface.
    For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
    For hot forged block, usually the delivery condition is hot forged, annealed/QT, milled surface/Black surface
    For hot rolled plate, usually the delivery condition is hot rolled, annealed/QT, black surface.
    For cold drawn bar, usually the delivery condition is cold drawn, annealed/QT, peeled/black surface

Hunan Qilu Metal Co., Ltd has the capacity to forge round steel, steel flat, square steel, module, shaft and roller, etc. The main specifications of the products include Φ80-1000mm forging materials and 80-1200mm square billets and which the maximum piece weight can reach 50T.

Company Main Products:(If you do not find the product you need, please contact us)

Hunan Qilu Metal Co., Ltd were already engaged in exporting steel for 11 years, could supply a great variety of hot forged, hot rolled and cold drawn Steels,  including engineering steel, cold work tool steel, hot work tool steel, plastic mold steel, spring steel, high speed steel, stainless steel etc., besides Qilu Metal also has their own heating treatment shop and machining shop to provide heating and cutting service.

Since 2008 year, Hunan Qilu Metal has the right to export all FORGED STEEL behalf of Qilu Speical Steel Co.,ltd which is specialized in smelting and forging of special steel since 1965 year, now Qilu special steel is one of the biggest manufacturer of forged product in China.The forged products are used in Automotive, Aerospace, Power Generation, Oil & Gas, Transportation and Industrial. We already set up the warehouse in Wuxi and Dongguan city, more than 20000 tons ex-stock could be supplied with kinds of size.

Qilu Metal is the professional one-stop steel manufacturer, stockist and exporter in China, our customers spread all over the world, include West Europe, North America, South America, Asia, Middle Asia, Africa, Australia, etc.

The company owns advanced special steel smelting facilities and forging processing equipments, the main steel-making equipment include 2 sets of 50t ultra-high power electric arc furnaces,2 sets of 60t LF refining furnaces,1 set of 60t vacuum degassing refining furnace and 4 sets of 1-20t electroslag re-melting furnaces.
The main forging equipments mainly include:3 sets of 5t electro-hydraulic hammers, 1 set of high-speed forging units of 800t,1600t,2000t and 4500t respectively.

Q1:Are you trading company or manufacturer ?
We are professional manufacturer for many years. we can provide a wide range of steel products.

Q2:What is alloy steel round bar export packing?

Usually bundling for large diameter,small diameter bars in bulk or as customer's demand.

Q3.What is your MOQ?

We accept small order,if it is stock,any quantities can be accepted.

Q4.What is your lead time?

Depends actual order,around 20-35 days,or negotiation.

Q5.Can you supply sample?

Yes,we can.Sample fee according to your size.

 Q6:What certificates do you have?

ISO, ABS, BV, CCS, Dnv, Lr, Gl, Mill Certificate

Q7: How can I get your quotation as soon as possible?
The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement,we will work out a best price soon.

Any interests in our company and products, please feel free to contact us for quotation. We warmly welcome you to our factory.
