Product Overview

Description



Products Description


Product Name
4+2 10/100Mbps AI Port Restart PoE Switch
Model
QF304EP-2E
Function
PoE
Package
1 pcs/ box. 20 boxes/carton


4+2 10/100Mbps AI Port Restart PoE Switch
This new 6 ports PoE switch provides power and data from a single point, using Power over Ethernet(PoE) over a single Cat5 cable. It can be used for any 10/100Mbps link and supply industry-standard IEEE 802.3af /at power. Advanced auto-sensing algorithm gives power to 802.3af/at end devices,In addition,the PoE switch automatically determines PoE requirements, speed, duplex. Easy to operate and reliable. . It also provides a switch button to extend the Ethernet transmission distance of 4 POE Ethernet ports up to 250m which make the installation more flexible.

This PoE switch is ideal for powering PoE devices such as IP cameras,WLAN access points, IP phones, office access control systems, and other PD devices and offers a line of high quality products that provide a total solution for ethernet application in different environments.


Features


  • Features

● Fully IEEE802.3af/at standard compliant.
● Support PoE power up to 15.4/30W for each
PoE ports.
● Support 250m PoE distance transmission
● Plug & Play. No configuration required.
● Reliable and great value.


Product Paramenters


Model
QF304EP-2E

Ports description
POE port
1-4ports:10/100M Auto-Negotiation RJ45
UPlink port
5-6port:10/100M Auto-Negotiation RJ45

POE power
MAX POE output
25.5W
Total power consumption
65W
POE port priority
Support
LED indicators
PWR(Power indicator light)、 POE(POE indicator)、Link/Act(Link / activity indicator)
Proccessing types
Store and forward
Transmission model
IEEE802.3X full-duplex and Backpressure half-duplex


Performance specification
Backplane bandwidth
1.2Gbps
Packet forwarding rate
0.72Mpps
MAC address
1k


Network standard
IEEE802.3i 10 BASE-T
IEEE802.3u 100 BASE-TX
IEEE802.3x Flow Control
IEEE802.3af Power over Ethernet
IEEE802.3at Power over Ethernet
IEEE802.3az EEE
Input volatage
AC220V. 50/60Hz, total 75W power
Weight
0.4KG
Dimension
203mm x 140mm x 44.5mm(W×D×H)
Cable requirements
UTP cat5 or abover

Environment specification
Operating temperature: -10℃~45℃，operating humidity: 10％~90％
Storage temperature: -20℃~70℃，storage humidity: 5％~95％


Certifications




Product Plug and Transport


1. Input: AC100-240V 50/60Hz
2.Support different plugs according to customer needs
1. Sample orders: Usually shipped by international express delivery
2. Bulk orders: Arrange freight according to the customer's designated freight forwarder
