AHD Camera Specification | ||
Product name | AHD Camera | |
Image Resolution | 2MP( 1920*1080) | |
Image Sensor | 2MP CMOS image sensor | |
Signal System | PAL & NTSC Optional ( Pls leave a note to inform which system you need ) | |
Lens | 3.6mm/6mm optional Fixed lens | |
LED | 35pcs of F5 LED | |
Infrared distance | 10-15m | |
Day & Night | IR cut filter | |
Data Storage Options | DVR | |
Audio | Built in Mic | |
Image Compression | H.264 | |
Sync System | Internal | |
Interface | Power interface + BNC video output interface | |
Waterproof | IP66 | |
Material | Metal & Plastic housing | |
Power Supply | DC12V | |
Operating temperature | -20℃~+55℃,RH 95% Max | |
Storage Temperature | -20℃~+60℃,RH 95% Max | |
AHD DVR Specification | ||
Model | 2MP 8CH DVR | |
Video output | 1 HDMI high-definition output, 1 VGA output | |
Video input | 8CH BNC interface | |
Network interface | RJ45 10M/100M Adaptive Ethernet port | |
USB interface | 2 USB 2.0 ports | |
Hard disk interface | 1 SATA interface (each supports up to 8TB) | |
Video compression | H.264/H.265 | |
Video mode | Manual>Alarm>Motion Detection>Timing | |
Video query | Time point search, calendar search, event search, channel search | |
Backup method | Network backup, USB mobile hard disk, USB burning, SATA burning | |
Power supply | DC 12V 2A | |
Power consumption | <10W (without hard disk) | |
Working temperature | -10℃-+55℃ | |
