22m 25m 30m Mobile Telescopic Mast Tower Antenna Tower Mast with Guy Wire
- Category: >>>
- Supplier: Henan Yangbo Lightning Protection Technology Co. Ltd.
Share on (1600914980404):
Product Overview
Description
PRODUCT DESCRIPTION
Telescopic Mast Size and Weight Details | ||||||||||||||||
Type | Retracted Height | Die Height | Inner Pipe Diameter | Outer Pipe Diameter | Section | Dead Load(Kg) Includes stay wire and tent peg | Load-bearing | |||||||||
(M) | (M) | ø | ø | Number | Aluminium Alloy | Carbon Fiber | Routine | |||||||||
Manual Telescopic Mast | 4 | 2300 | 90 | 105 | 2 | 26 | 25 | 20 | ||||||||
5 | 2050 | 80 | 105 | 3 | 29 | 27 | 20 | |||||||||
6 | 2100 | 70 | 105 | 4 | 32 | 29.5 | 20 | |||||||||
8 | 2150 | 60 | 105 | 5 | 33 | 30 | 20 | |||||||||
10 | 2200 | 50 | 105 | 6 | 35 | 31.5 | 20 | |||||||||
12 | 2250 | 40 | 105 | 7 | 38 | 34 | 20 | |||||||||
15 | 2350 | 40 | 140 | 9 | 55 | 48 | 20 | |||||||||
18 | 2650 | 40 | 140 | 9 | 61 | 53 | 20 | |||||||||
20 | 2700 | 40 | 160 | 10 | 78 | 68 | 20 | |||||||||
22 | 3000 | 40 | 160 | 10 | 87 | 75 | ≤20 | |||||||||
25 | 2850 | 40 | 220 | 13 | 173 | / | ≤20 | |||||||||
30 | 3280 | 40 | 220 | 13 | 191 | / | ≤20 | |||||||||
Electric Telescopic Mast | 4 | 2390 | 105 | 105 | 2 | 38 | 37 | 20 | ||||||||
5 | 2440 | 105 | 105 | 3 | 40 | 38 | 20 | |||||||||
6 | 1800 | 105 | 105 | 5 | 45 | 43 | 20 | |||||||||
8 | 1900 | 105 | 105 | 7 | 52 | 49 | 20 | |||||||||
10 | 2150 | 120 | 120 | 7 | 62 | 58 | 20 | |||||||||
12 | 2200 | 120 | 120 | 8 | 70 | 66 | 20 | |||||||||
15 | 2450 | 140 | 140 | 9 | 88 | 81 | 20 | |||||||||
18 | 2800 | 160 | 160 | 9 | 99 | 89 | 20 | |||||||||
20 | 2800 | 160 | 160 | 10 | 105 | 95 | 20 | |||||||||
22 | 2840 | 220 | 220 | 11 | 175 | / | ≤20 | |||||||||
25 | 2940 | 220 | 220 | 13 | 189 | / | ≤20 | |||||||||
30 | 3240 | 220 | 220 | 13 | 211 | / | ≤20 | |||||||||
SPECIFICATION
Title goes here.
1.High-strength aluminum lloy profiles are used, which are highly corrosion-resistant; the inner wall of the cylinder is sealed and connected by high-pressure wear-resistant porcelain treatment.
2.It has a strong anti-rotation function.
3.With self-installation function, it is convenient to move and transport. It can detect and maintain the tip device to make it work normally.
4.Strong wind resistance, capable of resisting wind of 27m/s.
5. It has the structural characteristics of high
anti-corrosion, waterproof and dustproof, and long service life.
anti-corrosion, waterproof and dustproof, and long service life.
6.The lifting mode can be manual or electric alone, or integrated manual and electric.
FAQ
1.What is the wind resistance rating when fully extended?
0.4kn/m², and 0.7kn/m²is customizable.
0.4kn/m², and 0.7kn/m²is customizable.
2. Do you have an option with 30-40kg payload?
Our payload is 3kg-30kg, others are customizable.
3. When do we need steel rope to fix the mast?
Generally, when the height is more than 6m, steel rope is necessary.
4. Are only 220V available, or 12v can be ordered?
4. Are only 220V available, or 12v can be ordered?
Our mast is at 220V, others is customizable ?
5. Are additional cable retraction mechanisms available?
Of course
Of course
6. Are motorized rotational platforms are available?
Yes, you can equip it with a PTZ.
7.Do you have them in stock?
No, but generally, we can delivery within 7 days.
8. Can the mast be stable mid section ?
Yes, it can be stopped anywhere.
