Product Overview
Description
Aluminum Nitride Ceramic
Aluminum nitride ceramic (AlN) has excellent properties such as high thermal conductivity, high strength, high resistivity, small density, low dielectric constant, non-toxic, and thermal expansion coefficient matching with Si. It is a new type ceramic material with excellent comprehensive performance. Due to its extremely high thermal conductivity, aluminum nitride can meet the heat dissipation requirements of high-power devices such as optical communication, microwave communication, LED, and high-speed rail.
Advantages：
1.Very high thermal conductivity
2. Excellent electrical insulation
3. Low density
4.Similar linear expansion coefficient with Si
5.Extremely high hardness
2. Excellent electrical insulation
3. Low density
4.Similar linear expansion coefficient with Si
5.Extremely high hardness
Item | Unit | ALN 180W | ALN 220W | ALN 220W |
Color | - | Gray | Gray | Gray |
Density | g/cm3 | 3.3 | 3.3 | 3.28 |
Flexural Strength | MPa | ≥350 | ≥350 | ≥350 |
Compressive Strength | MPa | 2500 | ≥2500 | - |
Elastic Modulus | GPa | 320 | 320 | 320 |
Vickers Hardness (Load 500g) | HV0.5 | 10 | 9.5 | 9 |
Coefficient of Line Thermal Expansion | 10-6K-1 | 4.8 | 4.6 | 4.5 |
Thermal Conductivity(20℃) | W/m·K | 180 | 200 | 220 |
Volume Resistance at 20°C | cm | >1014 | >1014 | >1013 |
Dielectric Strength | KV/mm | ≥15 | ≥15 | ≥15 |
Dielectric Constant (1MHz) | εr | 9 | 8.8 | 8.6 |
Loss Tangent | 10-4 | 5 | 5 | 3 |
Application: abrasion resistant lining patch; patch type electronic component substrate; computer accessories.
strong current, strong voltage, high temperature and easy wear parts of electronic appliances and mechanical equipment.
strong current, strong voltage, high temperature and easy wear parts of electronic appliances and mechanical equipment.
Physical properties: insulation, shock resistance, high temperature resistance, wear resistance, high strength
