2L 5L 10L 15L Lab Small Mini Instant Coffee Chemical Egg Vacuum Stainless Steel Milk Spray Dryer Washing Powder Price
- Category: >>>
- Supplier: Shanghai Ruiyuan Michinery Co. Ltd.
Share on (1600917715482):
Product Overview
Description
Product Description
spray dryer is a kind of continuous atmospheric dryer.Use pneumatic or electric atomization device to make liquid high-speed centrifugal spray as fog droplet, make these fog droplet contact with the hot air in the drying chamber and instantaneous drying.
1. After the air passes through the filter and the heating device, it enters the hot air distributor on the top of the drying
room, and the hot air passing through the hot air distributor evenly enters the drying room and rotates in a spiral shape.
2. At the same time, the material liquid is sent to the centrifugal spray head (atomizer) installed at the top of the drying
chamber, and the material liquid is sprayed into performance mist droplets.
3. The contact surface area of the material liquid and the hot air is greatly increased, and the water evaporates quickly, and the finished product is dried in a very short time.
4. The powder is recovered by the collection tube at the bottom of the dryer, and the exhaust gas is discharged by the
centrifugal fan.
room, and the hot air passing through the hot air distributor evenly enters the drying room and rotates in a spiral shape.
2. At the same time, the material liquid is sent to the centrifugal spray head (atomizer) installed at the top of the drying
chamber, and the material liquid is sprayed into performance mist droplets.
3. The contact surface area of the material liquid and the hot air is greatly increased, and the water evaporates quickly, and the finished product is dried in a very short time.
4. The powder is recovered by the collection tube at the bottom of the dryer, and the exhaust gas is discharged by the
centrifugal fan.
Specification
Model | RY-1500 | LPG-5 | LPG-10 | LPG-15 | |||
Max capacity | 1500-2000 ml/h | 5000 ml/h | 10000 ml/h | 15000 ml/h | |||
Temperature range of inlet air | 40℃ ~ 300℃ | 50°C ~ 300°C | 50°C ~ 300°C | 50°C ~ 300°C | |||
Temperature range of outlet air | 40℃ ~ 140℃ | 30°C ~ 150°C | 30°C ~ 150°C | 30°C ~ 150°C | |||
Spray system | Two-fluid nozzle | Centrifugal nozzle | Centrifugal nozzle | Centrifugal nozzle | |||
Precision of temp | ±1 ℃ | ||||||
Dryer time | 1.0 ~ 1.5 S | ||||||
Speed of squirt pump | 50 ~ 2000 | 3000 | 5000 | 10000 | |||
Nozzle size | 1.0mm | \\ | \\ | \\ | |||
Heat source | Electric | ||||||
Company Profile
Certifications
Packing & Delivery
FAQ
1. who are we?
We are based in Shanghai, China, start from 2011,sell to North America(20.00%),South America(10.00%),Southeast
Asia(10.00%),Africa(10.00%),Mid East(10.00%),Eastern Asia(10.00%),Northern Europe(10.00%),Domestic Market(10.00%),Central
America(5.00%),South Asia(5.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
essential oil distiller,herb extraction tank,concentration machine,lab spray dryer,fall film evaporator
4. why should you buy from us not from other suppliers?
Ruiyuan Machinery--High-tech Enterprise Professional--Made high quality Service--To customer satisfaction
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,MoneyGram,PayPal,Western Union,Cash;
Language Spoken:English
We are based in Shanghai, China, start from 2011,sell to North America(20.00%),South America(10.00%),Southeast
Asia(10.00%),Africa(10.00%),Mid East(10.00%),Eastern Asia(10.00%),Northern Europe(10.00%),Domestic Market(10.00%),Central
America(5.00%),South Asia(5.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
essential oil distiller,herb extraction tank,concentration machine,lab spray dryer,fall film evaporator
4. why should you buy from us not from other suppliers?
Ruiyuan Machinery--High-tech Enterprise Professional--Made high quality Service--To customer satisfaction
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,MoneyGram,PayPal,Western Union,Cash;
Language Spoken:English
