Hangdahui ball bearing blower fans centrifugal mini 4pin pwm 5v 24v blower fan motor 6015 60x60x15mm dc air blower fan
- Category: >>>
- Supplier: Beijing Zihang Dahui Electronics Co. Ltd.
Share on (1600918570330):
Product Overview
Description
Hangdahui ball bearing blower fans centrifugal mini 4pin pwm 5v 24v blower fan motor 6015 60x60x15mm dc air blower fan
| NO. | Rated Voltage | Oprtating VOltage | Rated Gurrent | Speed | Max.Air Flow | Max.static Pressure | Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | MMH2O | inH2O | dB | |
| HB6015L05 | 5 | 4.0-5.75 | 0.23 | 3000 | 0.08 | 2.90 | 7.8 | 0.31 | 29.0 |
| HB6015M05 | 5 | 4.0-5.75 | 0.35 | 4000 | 0.11 | 3.80 | 14.7 | 0.58 | 38.5 |
| HB6015H05 | 5 | 4.0-5.75 | 0.50 | 5000 | 0.14 | 5.00 | 24.2 | 0.95 | 43.2 |
| HB6015L12 | 12 | 7.0-13.8 | 0.13 | 3000 | 0.08 | 2.90 | 7.8 | 0.31 | 29.0 |
| HB6015M12 | 12 | 7.0-13.8 | 0.23 | 4000 | 0.11 | 3.80 | 14.7 | 0.58 | 38.5 |
| HB6015H12 | 12 | 7.0-13.8 | 0.32 | 5000 | 0.14 | 5.00 | 24.2 | 0.95 | 43.2 |
| HB6015L24 | 24 | 14.0-27.6 | 0.09 | 3000 | 0.08 | 2.90 | 7.8 | 0.31 | 29.0 |
| HB6015M24 | 24 | 14.0-27.6 | 0.13 | 4000 | 0.11 | 3.80 | 14.7 | 0.58 | 38.5 |
| HB6015H24 | 24 | 14.0-27.6 | 0.18 | 5000 | 0.14 | 5.00 | 24.2 | 0.95 | 43.2 |
Double ball bearing large air volume mute
Connector
Other products
Company Information
FAQ
1 What are kinds of cooling fan or centrigugal fan supplied by your company?
Answer: we can provide DC cooling fan, AC cooling fan, EC cooling fan and blower fan.
2 What are kinds of information provided by the customer before inquiry?
Answer : please kindly advise the size, voltage, the type of bearing, the speed of fan , or air flow.
3 How many types bearing of our cooling fan are there in our compnay at present?
Answer : now we have two types bearing for the fan, sleeve and ball, working time of sleeve is for 30,000 hours, the ball is for 50,000 hours.
