Refrigeration and Heating Water Chiller and Heater Combo
- Category: >>>
- Supplier: Wuxi Guanya Refrigeration Technology Co. Ltd.
Share on (1600918674540):
Product Overview
Description
Refrigeration and Heating Water Chiller and Heater Combo
Products Description
Product Paramenters
Model | SUNDI- 125(W) | SUNDI- 135(W) | SUNDI- 155(W) | SUNDI- 175(W) | SUNDI-1A10(W) | SUNDI- 1A15(W) | |||||||
Temp range | -10 ~ +200 ℃ (optional: -120 ~ 350℃) | ||||||||||||
Medium temp. acccuracy | ±0.5℃ | ||||||||||||
Material temp. accuracy | ±1℃ | ||||||||||||
Heating power (KW) | 2.5 | 3.5 | 5.5 | 7.5 | 10 | 15 | |||||||
Cooling capacity (KW) AT | 200℃ | 2.5 | 3.5 | 5.5 | 7.5 | 10 | 15 | ||||||
20℃ | 2.5 | 3.5 | 5.5 | 7.5 | 10 | 15 | |||||||
-5℃ | 1.5 | 2.1 | 3.3 | 4.2 | 6 | 9 | |||||||
Circulation pump max L/min bar | 20 | 35 | 35 | 50 | 50 | 75 | |||||||
2 | 2 | 2 | 2 | 2 | 2.5 | ||||||||
Compressor | Mitsubishi | Emerson copeland vortex flexible | |||||||||||
Expansion valve | Emerson thermal expansion valve/danfoss thermal expansion valve | ||||||||||||
Evaporator | DANFOSS/KAORI Plate heat exchanger | ||||||||||||
Refrigerant | R-404A/R507C | ||||||||||||
Connection size | G1/2 | G3/4 | G3/4 | G1 | G1 | G1 | |||||||
Dimension cm | 45*65 *120 | 50*85 *130 | 55*100 *175 | 55*100 *175 | 70*100 *175 | 70*100 *175 | |||||||
Weight kg | 115 | 165 | 185 | 235 | 280 | 300 | |||||||
Power max 380V 50HZ | AC220V 3.6KW | 5.6KW | 7.5KW | 10KW | 13KW | 20KW | |||||||
Why Choose Us
Structural design principles and functional advantages
When the temperature is high, there is no evaporation of heat conducting medium, and the continuous temperature control of -90~195℃，-70~220℃，-55~250℃ and -25~300℃ can be realized without pressure.
Adopt the design of fully closed pipeline, reduce the demand of heat-transfer fluid, improve the heat utilization rate of the system, and achieve rapid temperature rise and fall. The heat conducting medium in the expansion vessel does not participate in the circulation, which can reduce the risk of moisture absorption and volatilization during the operation of the heat conducting medium.
Adopt the design of fully closed pipeline, reduce the demand of heat-transfer fluid, improve the heat utilization rate of the system, and achieve rapid temperature rise and fall. The heat conducting medium in the expansion vessel does not participate in the circulation, which can reduce the risk of moisture absorption and volatilization during the operation of the heat conducting medium.
Company Profile
Wuxi Guanya Refrigeration Technology Co., Ltd. specialized in the industrial chiller, environmental chamber, industrial freezer, thermostatic bath, multi-reactor chiller (TCU), recirculating air control system and ultra-low temp. water-cooled chiller.We are the technology leader for high precision thermoregulation solutions in research and development industry. Our products offer temperature control solutions for applications from -152 to +350℃.
Exhibition
LNEYA attends various exhibitions at home and abroad every year. At the exhibition, we show the latest research equipment of LNEYA. Every year, long-term cooperative customers will come to exhibitions and communicate with us. We are also actively developing new customers to provide them with high quality machines and services.
Certifications
So far, LNEYA has 11 patents of utility model authorized certificate.
As an enterprise certified by ISO9001, LNEYA has reached international standards in the integration of various management systems. The products of LNEYA, CE is used as a permit for the product to enter the European market.
FAQ
Q: How many years have your factory been established？
Our company was established in 2006, registered the LNEYA trademark in 2007 and began to develop industrial temperature control equipment.
Q: Are you a trader or a manufacturer？
We are a professional manufacturer of industrial temperature control equipment, and have agents in the United States, South Korea, Russia, Thailand and India.
Q: How long is the warranty?
One-year free warranty. During the warranty period, no maintenance fees and accessory fees will be charged (the cost of spare parts will be charged for instrument failure caused by human factors). After the warranty period, the equipment will be responsible for maintenance for life, and appropriate fees will be charged according to the actual maintenance costs.
Q: Do you provide customized services?
Of course, you only need to send your specific requirements, and we will provide you with the products you want.
Our company was established in 2006, registered the LNEYA trademark in 2007 and began to develop industrial temperature control equipment.
Q: Are you a trader or a manufacturer？
We are a professional manufacturer of industrial temperature control equipment, and have agents in the United States, South Korea, Russia, Thailand and India.
Q: How long is the warranty?
One-year free warranty. During the warranty period, no maintenance fees and accessory fees will be charged (the cost of spare parts will be charged for instrument failure caused by human factors). After the warranty period, the equipment will be responsible for maintenance for life, and appropriate fees will be charged according to the actual maintenance costs.
Q: Do you provide customized services?
Of course, you only need to send your specific requirements, and we will provide you with the products you want.
