Wholesale high quality Industrial Pneumatic Dome Gate Valve In Stainless Steel Material

 Powder dome valve originated from Shanghai ShengLi for powder mixing equipment in its feeding, discharging system and process technology, combined with more than ten years of use and verification, it can close the material flow effectively,quickly,reliably and long lifetime. it provides as a unique product to the powder production industry users.

Working principle:

The core of the dome valve is a cambered surface. The sealing ring is close to the specially designed core. When the valve is in the open position, the material passes through from the arc surface and the sealing ring of the sphere chamber, which not only reduces the friction and extrusion between the valve core and the material, but also does not cause the blockage and obstruction of the material. The sealing ring fixed on the valve body can also remove the material adhered to the arc surface and ensure the reliability of the valve seal.

The advantages of the dome valve are:
1. Compact structure and light weight.
2. No seal stuck or pressed when open.
3. Powder material will not crush and break when closed.
4, The inner space of the dome valve is large, and the material flow is not hindered.
5. Vacuum can be produced in the production process, and the vacuum level can reach 0.8MPa
6. Good applicability of oily materials and viscous materials.
7. The clamp type of dome valve can be cleaned frequently in the production process.
8. Bigger than DN250 valve can be installed with observation glass.
9. Easy to load and unload
10. Pressure sustainable: 0.2MPa.
11.Temperature range: -20 ℃ +200 ℃.
12. Surface treatment meets GMP requirements.
13. long service life.
14. Drive selection: manual, pneumatic, electric.
15. sealing materials: silicone rubber and fluorine rubber.

 Applicable special materials:
1. materials will be fermented,or corrosive.
2. the material is damp and will lump and harden.
3. materials are adhesive.
4. material will react and creat exhaust air.

 Shanghai Shengli Machinery Manufacturing Co., Ltd. specializes in technology of mixing equipment and auxiliary. with more than 30 years of technical experience, we devotes ourselves to the research of mixing equipment and conveying equipment, refitting and perfecting the existing mixing process system.It sells more than 30 provinces and cities nationwide and exports to East Asia, Europe, America, and Hong Kong and Taiwan.
Based on the experience of manufacturing mixing equipment, the company independently developed a new spherical valve, which is widely used in feeding and discharging for mixing equipment and conveying equipment and its auxiliary product and other fields, it also solves some difficult problems of the valve in conveying and sealing for powder and particulate.
