Processor Family | Intel® Xeon® Scalable 8100/8200 series - Intel® Xeon® Scalable 3100/3200 series |
Processor Core Available | 4 to 28 core, depending on model |
Processor Cache Installed | 8.25 - 38.50 MB L3, depending on processor |
Maximum Memory | 3.0 TB with 128 GB DDR4; 6.0 TB with HPE 512GB 2666 Persistent Memory Kit |
Memory Slots | 24 DIMM slots |
Memory Type | HPE DDR4 SmartMemory and Intel® Optane™ persistent memory 100 series for HPE, depending on model |
NVDIMM Type | HPE NVDIMM-N *Only available on 1st Generation Intel® Xeon® Scalable Processors |
NVDIMM Rank | Single rank |
NVDIMM Capacity | 16 GB |
Drive Supported | 4 LFF SAS/SATA, 8 SFF SAS/SATA + 2 NVMe, 10 SFF SAS/SATA, 10 SFF NVMe, 1 SFF or 1 Dual UFF rear drive optional depending on model |
Network Controller | Embedded 4 X 1GbE Ethernet Adapter (select models) or HPE FlexibleLOM and optional PCIe stand-up cards, depending on model |
Remote Management Software | HPE iLO Standard with Intelligent Provisioning (embedded), HPEE OneView Standard (requires download); Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses) |
System Fan Features | Hot-plug redundant standard |
Storage Controller | HPE Smart Array S100i and/or HPE Essential or Performance RAID controllers, depending on model |
Form Factor | 1U |
Weight (metric) | 13.04 kg minimum, 16.78 kg maximum |
Product Dimensions (metric) | SFF Chassis: 4.29 x 43.46 x 70.7 cm, LFF Chassis: 4.29 x 43.46 x 74.98 cm |
