80mm brushless Dc Motor with JKBLD 750 Driver applied to V groove cutting machine bldc motor neodymium magnet
80mm brushless Dc Motor with JKBLD 750 Driver applied to V groove cutting machine bldc motor neodymium magnet
80mm brushless Dc Motor with JKBLD 750 Driver applied to V groove cutting machine bldc motor neodymium magnet
80mm brushless Dc Motor with JKBLD 750 Driver applied to V groove cutting machine bldc motor neodymium magnet
80mm brushless Dc Motor with JKBLD 750 Driver applied to V groove cutting machine bldc motor neodymium magnet
80mm brushless Dc Motor with JKBLD 750 Driver applied to V groove cutting machine bldc motor neodymium magnet
80mm brushless Dc Motor with JKBLD 750 Driver applied to V groove cutting machine bldc motor neodymium magnet

80mm brushless Dc Motor with JKBLD 750 Driver applied to V groove cutting machine bldc motor neodymium magnet

Share on (1600922256537):


Price:$115.00 - $135.00

Quantity:


Product Overview

Description



Specification


item
value
Warranty
3months-1year
Place of Origin
China
Jiangsu
Brand Name
JK stepper motor
Model Number
JK80BLS
Usage
BOAT, Car, Electric Bicycle, FAN, Home Appliance
Type
BLS dc motor
Torque
1.0-2.5N.m
Construction
Shunt Wound
Commutation
Brushless
Protect Feature
Drip-proof
Speed(RPM)
6000Rpm
Continuous Current(A)
2.8-17.4A
Efficiency
IE 1
Body length
130-195.5mm
Stepper motor weight
1.85-3.5kg




Product Name: Brushless DC Motor
Number of Phase: 3 Phase
Number of Poles: 4 Poles /8 Poles /10 Poles
Rated Voltage: 24v /36v /48v /310v
Rated Speed: 3000rpm /4000rpm /or customized
Rated Torque: Customized
Rated Current: Customized
Rated Power: 23w~2500W

Model Name: JK86BLS BLDC Motor
Number of Phase: 3 Phase
Number of Poles: 8 Poles
Rated Voltage: 48v
Rated Speed: 3000rpm
Rated Torque: 0.35N.m~2.1N.m
Rated Current: 3A~18A
Rated Power: 110W~1000W
Customized Design: Customization accept, such as encoder, various gearbox, brake, or other parameters customer need.


Product Series
Poles No.
Rated Voltage
Rated Speed
Rated Torque
Rated Power
Motor Length
42mm BLDC Motor
8
24v
4000rpm
0.0625~0.25N.m
26~105w
41~100mm
57mm BLDC Motor
4
36v
4000rpm
0.055~0.44N.m
23~184w
37~107mm
60mm BLDC Motor
8
48v
3000rpm
0.3~1.2N.m
94~377w
78~120mm
80mm BLDC Motor
4
48v
3000rpm
0.35~1.4N.m
110~440w
78~138mm
86mm BLDC Motor
8
48v
3000rpm
0.35~2.1N.m
110~660w
71~138.5mm
110mm BLDC Motor
8
310v
3000rpm
1.65~6.6N.m
518~2073w
83~173mm
130mm BLDC Motor
10
310v
3000rpm
2.39~11.94N.m
750~2500w
115~190mm


86mm BLDC MOTOR SPECIFICATION:
Model
Model
Specification
Unit
JK86BLS58
JK86BLS71
JK86BLS84
JK86BLS98
JK86BLS125
Number Of Phase
Phase
3
Number Of Poles
Poles
8
Rated Voltage
VDC
48
Rated Speed
Rpm
3000
Rated Torque
N.m
0.35
0.7
1.05
1.4
2.1
Rated Current
Amps
3
6.3
9
11.5
18
Rated Power
W
110
220
330
440
660
Peak Torque
N.m
1.05
2.1
3.15
4.2
6.3
Peak Current
Amps
9
19
27
35
54
Back E.M.F
V/Krpm
13.7
13
13.5
13.7
13.5
Torque Constant
N.m/A
0.13
0.12
0.13
0.13
0.13
Rotor Inertia
g.c㎡
400
800
1200
1600
2400
Body Length
mm
71
84.5
98
111.5
138.5
Weight
Kg
1.5
1.9
2.3
2.7
4


Above only for representative products, products of special request can be made according to the customer request.


80 / 86mm Planetary Gearbox Parameters:


Suitable brushless dc motor shaft



Motor Shaft Pinion Specifications



Module
1


No. of teeth
12
13
22
Pressure angle
20°


Hole diameter
10 teeth pinion
Φ7H7
Φ8H7
Reduction ratio
1/6.6 1/23 1/26 1/37 1/92 1/138
1/5.31 1/19 1/30 1/74 1/111
1/3.55 1/13 1/50


Gearbox Specifications:
Reduction ratio
Exact reduction ratio
Rated tolerance torque
Max momentary tolerance torque
Efficiency
L (mm)
Weight (g)
1/3.55 1/5.31 1/6.6
1/3.55 1/5.31 1/6.6
8 N.m Max
12N.m
90%
55.7±0.5
1100
1/13 1/19 1/23
1/12.57 1/18.82 1/23.4
30 N.m Max
45N.m
81%
72.2±0.5
1500
1/26 1/30 1/37
1/26.05 1/30.08 1/37.4
60 N.m Max
90N.m
73%
72.2±0.5
1500
1/50 1/74 1/92 1/111 1/138
1/49.62 1/74.28 1/92.37 1/111.2 1/138.28
80 N.m Max
120N.m
66%
88.5±0.5
1880












Different Kinds of Planetary Gear Reducer for your reference






42mm BLDC MOTOR SPECIFICATION:
Model
Specification
Unit
JK42BLS01
JK42BLS02
JK42BLS03
JK42BLS04
Number Of Phase
Phase
3
Number Of Poles
Poles
8
Rated Voltage
VDC
24
Rated Speed
Rpm
4000
Rated Torque
N.m
0.0625
0.125
0.185
0.25
Rated Current
Amps
1.8
3.3
4.8
6.3
Rated Power
W
26
52.5
77.5
105
Peak Torque
N.m
0.19
0.38
0.56
0.75
Peak Current
Amps
5.4
10.6
15.5
20
Back E.M.F
V/Krpm
4.1
4.2
4.3
4.3
Torque Constant
N.m/A
0.039
0.04
0.041
0.041
Rotor Inertia
g.c㎡
24
48
72
96
Body Length
mm
41
61
81
100
Weight
kg
0.3
0.45
0.65
0.8


57mm BLDC MOTOR SPECIFICATION:
Model
Model
Specification
Unit
JK57BLS005
JK57BLS01
JK57BLS02
JK57BLS03
JK57BLS04
Number Of Phase
Phase
3
Number Of Poles
Poles
4
Rated Voltage
VDC
36
Rated Speed
Rpm
4000
Rated Torque
N.m
0.055
0.11
0.22
0.33
0.44
Rated Current
Amps
1.2
2
3.6
5.3
6.8
Rated Power
W
23
46
92
138
184
Peak Torque
N.m
0.16
0.33
0.66
1
1.32
Peak Current
Amps
3.5
6.8
11.5
15.5
20.5
Back E.M.F
V/Krpm
7.8
7.7
7.4
7.3
7.1
Torque Constant
N.m/A
0.074
0.073
0.07
0.07
0.068
Rotor Inertia
g.c㎡
30
75
119
173
230
Body Length
mm
37
47
67
87
107
Weight
Kg
0.33
0.44
0.75
1
1.25


60mm BLDC MOTOR SPECIFICATION:
Model
Specification
Unit
JK60BLS01
JK60BLS02
JK60BLS03
JK60BLS04
Number Of Phase
Phase
3
Number Of Poles
Poles
8
Rated Voltage
VDC
48
Rated Speed
Rpm
3000
Rated Torque
N.m
0.3
0.6
0.9
1.2
Rated Current
Amps
2.8
5.2
7.5
9.5
Rated Power
W
94
188
283
377
Peak Torque
N.m
0.9
1.8
2.7
3.6
Peak Current
Amps
8.4
15.6
22.5
28.5
Back E.M.F
V/Krpm
12.1
12.6
12.4
13.3
Torque Constant
N.m/A
0.116
0.12
0.118
0.127
Rotor Inertia
g.c㎡
0.24
0.48
0.72
0.96
Body Length
mm
78
99
120
141
Weight
Kg
0.85
1.25
1.65
2.05


80mm BLDC MOTOR SPECIFICATION:
Model
Specification
Unit
JK80BLS01
JK80BLS02
JK80BLS03
JK80BLS04
Number Of Phase
Phase
3
Number Of Poles
Poles
4
Rated Voltage
VDC
48
Rated Speed
Rpm
3000
Rated Torque
N.m
0.35
0.7
1.05
1.4
Rated Current
Amps
3
5.5
8
10.5
Rated Power
W
110
220
330
440
Peak Torque
N.m
1.05
2.1
3.15
4.2
Peak Current
Amps
9
16.5
24
31.5
Back E.M.F
V/Krpm
13.5
13.3
13.1
13
Torque Constant
N.m/A
0.13
0.127
0.126
0.124
Rotor Inertia
g.c㎡
210
420
630
840
Body Length
mm
78
98
118
138
Weight
Kg
1.4
2
2.6
3.2












Changzhou Jkongmotor Co., Ltd was a high technology industry zone in changzhou, china. Our products used in many kinds of machines, such as 3d printer CNC machine, medical equipment, weaving printing equipments and so on.
JKONGMOTOR warmly welcome 'OEM' & 'ODM' cooperations and other companies to establish long-term cooperation with us.
Company spirit of sincere and good reputation, won the recognition and support of the broad masses of customers, at the same time with the domestic and foreign suppliers close community of interests, the company entered the stage of stage of benign development, laying a solid foundation for the strategic goal of realizing only really the sustainable development of the company.












1. Can you make the gearbox or gearmotor with custom specifications?
YES. We have strong R&D capability, also a great term of engineers, each of them have many work years experience.

2. Do you provide the samples?
YES. Our company can provide the samples to you

3.Do you provide technology support?
YES. Our company have strong R&D capability, we can provide technology support if you need.

4. why should you buy from us not from other suppliers?
Professional one-to-one motor customized . The world's large enterprise of choice for high quality suppliers . ISO9001:2008 quality management system certification, through the CE, ROHS certification.

5. How to ship to us?
We will ship the samples to you according to the DHL or UPS or FEDEX etc account you provide.

6. How can I know the product is suitable for me?
Frist, you need to provide us the more details information about the product. We will recommend the item to you according to your requirement of specification. After you confirm, we will prepare the samples to you. also we will offer some good advances according to your product use.
