APP Remote Control Ios Android Zigbee Wifi Ph Npk Sensor Meter Linkage Smart water timer Soil Moisture Temperature Detector
- Category: >>>
- Supplier: Shenzhen Power-Tomorrow Actuator Valve Co. Ltd.Shenzhen Ltd.
Share on (1600922441147):
Product Overview
Description
Product Description
App Ios Android Zigbee Wifi Soil temperature and humidity Sensor For Garden plants
The soil sensor is equipped with a humidity/temperature sensor. The temperature measurement range is -20°C to 60°C with an accuracy of ±1°C. The moisture measurement range spans 0-100%, with an optimum soil moisture of 40-70%. Help you monitor the temperature and humidity of plant soil.
Utilize the Zigbee gateway to realize wireless long-distance transmission, through the smart life APP, you can monitor and record daily, monthly and annual charts of soil moisture and temperature readings in real time. Easy-to-read graphs make it easy to track your plants' growth progress over time.
Soil moisture and temperature sensors are designed for indoor and outdoor use. Made of 304 stainless steel, anti-rust, acid and alkali resistance, long service life. The waterproof rating is IP67 to withstand harsh weather. Features low power consumption, high-sensitivity measurements, and stable industrial-grade performance.
The soil tester is suitable for all kinds of soils. Such as potted flower boxes, courtyard gardens, farmland vegetable fields, greenhouses, lawns and other scenes. Please note that the soil tester is only for testing clay and soil and not for flour, small stones, organic wood chips, liquid pellets and similar materials.
The monitoring results of the plant monitor are accurate and reliable, and it can be inserted into the soil for a long time without damage, which is the most prominent feature compared with other soil testers. NOTE: The smart soil sensor must be used with a ZigBee gateway (the gateway is not included with this product).
Utilize the Zigbee gateway to realize wireless long-distance transmission, through the smart life APP, you can monitor and record daily, monthly and annual charts of soil moisture and temperature readings in real time. Easy-to-read graphs make it easy to track your plants' growth progress over time.
Soil moisture and temperature sensors are designed for indoor and outdoor use. Made of 304 stainless steel, anti-rust, acid and alkali resistance, long service life. The waterproof rating is IP67 to withstand harsh weather. Features low power consumption, high-sensitivity measurements, and stable industrial-grade performance.
The soil tester is suitable for all kinds of soils. Such as potted flower boxes, courtyard gardens, farmland vegetable fields, greenhouses, lawns and other scenes. Please note that the soil tester is only for testing clay and soil and not for flour, small stones, organic wood chips, liquid pellets and similar materials.
The monitoring results of the plant monitor are accurate and reliable, and it can be inserted into the soil for a long time without damage, which is the most prominent feature compared with other soil testers. NOTE: The smart soil sensor must be used with a ZigBee gateway (the gateway is not included with this product).
Specification
Features
* Check soil temperature and humidity remotely and in real time.
* Create different watering automations.
* Stainless steel probe, accurate measurement, corrosion resistance, electrolysis resistance, stable performance.
* IP67 waterproof, prevent moisture from entering inside the body, good sealing.
* Suitable for a variety of soil types and can be used in potted plants, vegetable greenhouses, farmland vegetable fields, lawns
and other places.
* Attention: only support Tuya Zigbee APP.
* When using the product, it must be associated with a Tuya gateway (a box Tuya Lidl, Woox, We etc).
* Create different watering automations.
* Stainless steel probe, accurate measurement, corrosion resistance, electrolysis resistance, stable performance.
* IP67 waterproof, prevent moisture from entering inside the body, good sealing.
* Suitable for a variety of soil types and can be used in potted plants, vegetable greenhouses, farmland vegetable fields, lawns
and other places.
* Attention: only support Tuya Zigbee APP.
* When using the product, it must be associated with a Tuya gateway (a box Tuya Lidl, Woox, We etc).
Packing & Delivery
Company Profile
Shenzhen Power-Tomorrow Actuator Valve Co.,Ltd, started on 21st,Nov,2017, a high-tech company of IoT flow automation with the nucleus of Internet of thing+smart hardware, has created QOTO smart irrigation system and obtained multiple patents. The smart valves and valve controllers developed by our own for small and medium sized pipelines have been applied in
municipal landscaping and agricultural irrigation, meeting different requirements from users and scenarios.After years of accumulations on experience and technology, QOTO has been the leader of remote control smart motorized valve, pushing forward the developing of IoT flow control.
municipal landscaping and agricultural irrigation, meeting different requirements from users and scenarios.After years of accumulations on experience and technology, QOTO has been the leader of remote control smart motorized valve, pushing forward the developing of IoT flow control.
FAQ
1. How to make soil moisture sensor last longer
A. Vertical insertion of the sensor: Insert the sensor 90 degrees vertically into the soil to be tested. Do not shake the sensor when inserting it to prevent the sensor probe from being bent and damaging the probe.
B. Horizontal insertion of multiple sensors: Insert the sensors into the soil to be tested in parallel. This method is used for multi-layer soil moisture detection. Do not shake the sensor when inserting it to prevent the sensor probe from being bent and damaging the steel needle.
C. When you feel that there are lumps or foreign objects in the tested soil, please reselect the location of the tested soil, or remove the lumps in the current soil, and then continue testing.
D. When storing the soil sensor, wipe the three stainless steel needles clean with dry paper towels, cover them with foam, and store them in a dry environment at 0-60°C.
2. What means depth of soil in soil moisture sensor?
For different soil depths, the water content is different, so the value measured by the soil moisture sensor is also different. The soil moisture sensor can be buried in the soil to measure, so you can choose a suitable soil depth for measurement. It varies according to the type of plant and the texture of the soil. If the tree grows in dry soil or hilly areas, the vertical roots can be as deep as 12 meters. For some vegetables, the roots are about 1 meter deep into the soil. The best water measurement depth for ordinary crops is 5-9 cm.
3. How to maintain the soil moisture sensor?
About soil moisture sensor maintenance:
A. When using the soil moisture sensor, the stainless steel probe must be fully inserted into the soil, avoid rocks, and do not damage the steel needle.
B. The housing of the sensor is potted with black epoxy resin, so try to avoid damage to the housing caused by high temperature or direct sunlight. Pay attention to lightning protection when using in the field.
C. Do not drop or violently hit the sensor and probe during installation or storage. Do not expose the signal wire of the sensor in a place with high temperature or high humidity.
D. After using the soil moisture sensor, wipe the soil and moisture on the probe clean.
A. Vertical insertion of the sensor: Insert the sensor 90 degrees vertically into the soil to be tested. Do not shake the sensor when inserting it to prevent the sensor probe from being bent and damaging the probe.
B. Horizontal insertion of multiple sensors: Insert the sensors into the soil to be tested in parallel. This method is used for multi-layer soil moisture detection. Do not shake the sensor when inserting it to prevent the sensor probe from being bent and damaging the steel needle.
C. When you feel that there are lumps or foreign objects in the tested soil, please reselect the location of the tested soil, or remove the lumps in the current soil, and then continue testing.
D. When storing the soil sensor, wipe the three stainless steel needles clean with dry paper towels, cover them with foam, and store them in a dry environment at 0-60°C.
2. What means depth of soil in soil moisture sensor?
For different soil depths, the water content is different, so the value measured by the soil moisture sensor is also different. The soil moisture sensor can be buried in the soil to measure, so you can choose a suitable soil depth for measurement. It varies according to the type of plant and the texture of the soil. If the tree grows in dry soil or hilly areas, the vertical roots can be as deep as 12 meters. For some vegetables, the roots are about 1 meter deep into the soil. The best water measurement depth for ordinary crops is 5-9 cm.
3. How to maintain the soil moisture sensor?
About soil moisture sensor maintenance:
A. When using the soil moisture sensor, the stainless steel probe must be fully inserted into the soil, avoid rocks, and do not damage the steel needle.
B. The housing of the sensor is potted with black epoxy resin, so try to avoid damage to the housing caused by high temperature or direct sunlight. Pay attention to lightning protection when using in the field.
C. Do not drop or violently hit the sensor and probe during installation or storage. Do not expose the signal wire of the sensor in a place with high temperature or high humidity.
D. After using the soil moisture sensor, wipe the soil and moisture on the probe clean.
