Deck Continuous Steel Truss Bridge Fast Delivery Modular Bailey

Product Overview

Description

 Deck Continuous Steel Truss Bridge Fast Delivery Modular Bailey





Known as a portable prefabricated steel truss bridge, Bailey Bridge is extensively used in various applications. Developed and introduced in 1940's by an English Civil Servant and Engineer, Sir Donald Bailey. Used during the second world war by the British, Canadian, and Military units. The concept behind the Bailey Bridge was to offer a temporary bridge that could rapidly and manually be created in emergency situations.



This was due to its girder and deck systems that can be strengthened at will and constructed without requiring special tools or heavy equipment. The elements and materials should be readily available, not necessarily big and light but flexible. On top of this, they should be strong enough to carry and sustain loads like those of heavy tanks and other machineries.



The bridge boosts socio-economic development by establishing vital connections and delivering supplies, especially to distant areas. They are instrumental in assisting isolated villages to this day to access larger communities where education and medical resources may be more available. Bailey Bridges can assist significantly during humanitarian relief situations to extend help in emergencies brought by natural disasters, war, or terrorism.



Bailey Bridges we supply can span up to 67meters. Composed of steel truss panels, these elements are connected together by bolts and pins. The installation completed for panel bridges does not require any specific tools or heavy equipment, and all these elements can be handled manually by a team of 6 workers.



Specifications:

Single lane	STD Carriageway Net Width: 4.2m	Single span: 18m-67m
Double lane	STD Carriageway Net Width:7.35m	Single span: 18m-67m

Bridge deck	Anti-slip steel decking floor,checkered steel plate etc
Steel grade	Q345B/Q355 (equivalent to ASTM A572) or custom required
Loading capacity	20ton, 40ton truck etc, or HS20-44, HS25-44/Truck 20/HL-93
