Model

The output voltage

The input voltage

PD96100-100

0-100V

0-100A

Input

phase

Single phase

Voltage

220V±10%

Frequency

47hz-63hz

Output

Power

10KW

Voltage

0~100V adjustable

Current

0~100A adjustable

Ripple

≤1%+10mVrms

Power regulation rate

≤1%+30mV

Load Regulation

≤±1%

Circuit Mode

PWM

Efficiency

≥85%

Protection

Overvoltage Overcurrent Overtemperature Short circuit Reverse

Voltmeter, resolution

Five-digit digital meter, 0.01V

Ammeter, resolution

Five-digit table, 0.01A

Timetable, resolution

Five digits meter, 0.1S

Power meter, resolution

Five-digit digital meter, 0.1W

Reading accuracy

Voltage

±0.5%rdg ± 2digit(10%-100% Rated value )

Current

±0.5%rdg ± 2digit(10%-100% Rated value )

environment

Working Temp

0~40℃

Working RH

10%~90% RH  ( No condensation )

Cooling

Fan forced cooling

communication method

RS232/RS485(optional)

Insulation

Input to case 20MΩ 500VDC, output to case 20MΩ 500VDC

Pressure  resistance

Input to chassis 1500VAC for 1 minute, input to output 1500VAC for 1 minute

Input mode

Wiring block

Output mode

Wiring copper post

Size W×H×D (mm)

430*430*550

Weight  (KG)

40

Configuration

Desktop
