BOE FOG 10.1 inch 1920x1200 industri lcd screen 1000nits brightness with LVDS to MIPI converter board

This is a BOE FOG 10.1 inch 1920x1200 industri lcd screen 1000nits brightness with LVDS to MIPI converter board

(1) The 10.1-inch MIPI screen is made of BOE original glass.

(2) Requirements for LVDS signal is provided by the motherboard:

Lcd0_ Clk=157;

Lcd0_ X=1200;

Lcd0_ Y=1920;

Lcd0_ Hbp=32;

Lcd0_ Hfp=100;

Lcd0_ Hspw=10;

Lcd0_ Vfp=10;

Lcd0_ Vbp=15;

Lcd0_ Vspw=5;

(3) Bill of Materials:

    a. Backlight board, backlight wire;

    b. 10.1-inch screen+LVDS to MIPI board, as well as screen connecting cables.

Just need the customer to provide the LVDS motherboard, everything else is sold together as a complete set. If the RK3288 motherboard needs to be matched, an additional payment is required.

We supply all kinds of display modules: TFT, LCOS, OLED, touch etc.

Touch screen LCD assembly, smart HMI display, OLED,FLCOS,micro display modules are popular product now.

Control Electronic Co.,Ltd. was founded in 2008 in Shenzhen.

Before that,the leaders had been in LCD panel industry for more than 6 years.

We mainly supply A grade new LCD panels from InnoLux and AUO.

Our engineer has 9 years' experience working in InnoLux.

Matching touch panels and driver boards are also available.

To spread our business,we had a new office in Shanghai this year.

We can trade in China mainland,HK or send goods to your destination.

Products are mainly used in industry control,security system,medical device,tablets,advertising machine and other instruments about display.

We look forward to cooperations and comments from you.

 For more products and information, please contact us directly.
