DC 5V 5 Ports Full Network Switch Ethernet Switch 5port support 10/100Mps
- Category: >>>
- Supplier: Shenzhen Eborm Technology Co. Ltd.
Share on (1600925007440):
Product Overview
Description
Product Description
Ø 5*100M Ethernet port with auto-negotiation function
Ø Support 100M speed rate,MDI/MDIX
Ø Support IEEE802.3x Flow control and back pressure control
Ø Each port has the complete LED Indicator light
Ø Support IEEE802.1d Spanning Tree
Ø Each port supports wire-speed switching ,64~1518 frame length can reach the wire speed
Ø Support high performance QoS function on each port
Ø Support multicast to avoid network congestion
Ø Support 5-16V voltage input
Ø Support 4K lightning protection of each port
Ø Require no configuration and will instantly operate as soon as you power it up
Ø Use low-power consumption chips,only 2.5W in full load conditions
Standards | IEEE802.3 10Base-T IEEE802.3u 100Base-TX/FX | IEEE802.3x Flow control IEEE802.1p QoS IEEE802.1d Spanning Tree |
Certifications | CCC, CE | |
Ethernet Port | Ø Connector: RJ45 Ø Data Rate: 10/100M Ø Distance: 100m Ø UTP Type: UTP-5E or higher level | |
Performance | Ø Processing Type: Store and Forward Ø Transmission Mode: half/full-duplex with auto-negotiation function Ø MAC Table Size: 1K Ø Buffer Space: 448K Ø Back bandwidth: 1G Ø Time Delay: <150μs | |
Power | Ø Power type: external power supply Ø Input Voltage: AC100V~240V 50/60Hz Ø Connector: DC Socket Ø Working Voltage: 5V Ø Power Consumption: 1.8W~4W | |
Environment | Ø Storage Temperature: -40~70℃ Ø Operating Temperature: -10~55℃ Ø Relative Humidity: 5-90% ( no condensation) | |
Warranty | 2 year | |
Physical Characteristics | Ø Dimension: 100×52×28mm Ø Weight: 0.30kg Ø Color: Plastic, Black | |
