Factory Supply Hollow Rotary Actuator Cnc Rotary Table Agv Gearbox Planetary Reducer Drive Wheel VI 16 0288 N Slewing Bearings
Factory Supply Hollow Rotary Actuator Cnc Rotary Table Agv Gearbox Planetary Reducer Drive Wheel VI 16 0288 N Slewing Bearings
Factory Supply Hollow Rotary Actuator Cnc Rotary Table Agv Gearbox Planetary Reducer Drive Wheel VI 16 0288 N Slewing Bearings
Factory Supply Hollow Rotary Actuator Cnc Rotary Table Agv Gearbox Planetary Reducer Drive Wheel VI 16 0288 N Slewing Bearings
Factory Supply Hollow Rotary Actuator Cnc Rotary Table Agv Gearbox Planetary Reducer Drive Wheel VI 16 0288 N Slewing Bearings
Factory Supply Hollow Rotary Actuator Cnc Rotary Table Agv Gearbox Planetary Reducer Drive Wheel VI 16 0288 N Slewing Bearings
Factory Supply Hollow Rotary Actuator Cnc Rotary Table Agv Gearbox Planetary Reducer Drive Wheel VI 16 0288 N Slewing Bearings

Factory Supply Hollow Rotary Actuator Cnc Rotary Table Agv Gearbox Planetary Reducer Drive Wheel VI 16 0288 N Slewing Bearings

Share on (1600925794747):


Price:US$599.99

Quantity:


Product Overview

Description







Four-point contact ball bearing is radial single row angular contact ball bearings with raceway that is designed to support axial loads in both directions. For a given axial load, a limited radial load can also be beared.

Four-point contact bearings are single-row bearings, and therefore require significantly less space in an axial direction than double-row designs.The bearings comprise solid outer rings, split inner rings and ball and cage assemblies with brass or polyamide cages. The two-piece inner rings enable a large complement of balls to be accommodated. The inner ring halves are matched to the particular bearing and must not be interchanged with those of other bearings of the same size. The outer ring with the ball and cage assembly can be mounted separately from the two inner ring halves.


VA SERIES
External Gear Slewing Bearing
VI SERIES
Internal Gear Slewing Bearing
VU SERIES
None Gear Slewing Bearing


Remark: details structure drawing please contact supplier LISA LEE 008618137917388 or lyave@qq.com


Model No.
di (mm)
Da (mm)
H (mm)
Mass (kgs)
VA 140188 V
135
259.36
28
7.5
VA 160235 N
171
318.6
41.5
13
VA 160302 N
238
384
52.5
14
VA 250309 N
235
408.4
66
29.5
VI 160288 N
216
340
39
12
VI 140326 V
250
382
59
18
VI 160420 N
332
486
39
23
VU 140179
124.5
234
35
7
VU 200220
138
302
46
16
VU 130225
200
290
24
5.4
VU 200260
191
329
46
15
VU 140325
270
380
35
12
VU 250380
275
485
55
44
VU 200405
336
474
46
25
VU 250433
344
522
55
41
VU 300574
468
680
68
82
VU 360680
565
795
79
120
