AZ31 Magnesium alloy tube,Magnesium alloy extruded tube/pipe/bar
- Category: >>>
- Supplier: Shanghai Yila Stainless Steel Products Co. Ltd.
Share on (1600928353200):
Product Overview
Description
Product Show
AZ31 Magnesium alloy tube,Magnesium alloy extruded tube/pipe/bar
Product Description
Application:
(magnesium alloy tube bar rod )
*Etching engraving
*Automotive
*Transportation
*Aerospace industries
*Cathodic protection
*Production of intricate motor sport parts
*Monocoque construction
*Chassis components
*Race chassis ,structural engine parts
*Hydraulics
Chemical compositions of magnesium ribbon anodes (%) | ||
Element | High potential | |
Al | <0.01 | |
Zn | --- | |
Mn | 0.5-1.30 | |
Si (max) | 0.05 | |
Cu (max) | 0.02 | |
Ni (max) | 0.001 | |
Fe (max) | 0.03 | |
Others each | 0.05 | |
Others total | 0.3 | |
Mg | Balance | |
Electrochemical Properties magnesium ribbon anodes | ||||||||
Item | Open-circuit Voltage | Close-circuit Voltage | Actual capacitance | Current efficiency | ||||
(-V) | (-V) | (A.h/g) | (%) | |||||
High Potential | 1.70-1.75 | 1.57-1.62 | ≥ 1.100 | ≥ 50 | ||||
Steel core diamter: 3.4mm
Unit weight: around 0.36 kg/meter
Coil length: 305 meters /coil
Coil unit weight: 110 kgs/coil
Yila's advantage
1.Various size of magnesium material in stock
2. Direct factory
3.Strict inspection and fast delivery (MTC will be attached)
4.Short delivery and size can be customzied
5.Quite professional with great experience
2. Direct factory
3.Strict inspection and fast delivery (MTC will be attached)
4.Short delivery and size can be customzied
5.Quite professional with great experience
Chemcial Composition
Model | Chemical Component(%): | ||||||||||||
Type | Mg | Al | Zn | Mn | Si | Fe | Cu | ||||||
AX31B | residual | 2.5-3.5 | 0.60-1.4 | 0.20-1.0 | ≤0.08 | ≤0.003 | ≤0.001 | ||||||
AZ61A | residual | 5.8-7.2 | 0.40-1.5 | 0.15-0.50 | ≤0.10 | ≤0.005 | ≤0.005 | ||||||
AZ80A | residual | 7.8-9.2 | 0.20-0.80 | 0.12-0.50 | ≤0.10 | ≤0.005 | ≤0.005 | ||||||
AZ91D | residual | 8.5-9.5 | 0.45-0.90 | 0.17-0.40 | ≤0.08 | ≤0.004 | ≤0.001 | ||||||
♦ Physical Properties :
Density: 1.8Coefficient of thermal expansion: 26.8 x 10-6K-1
Specific heat: 1040 Jkg-1k-1
Thermal conductivity: 76.9Wm-1k-1
Electrical resistivity: 92nΩm
Modulus of elasticity: 45 x 109Pa
Poissons ratio: 0.35
Melting range: 566 - 632°C.
One-Stop Service
Laser cutting
Slitting
Water Jet Cutting
Heat treatment
Polishing
Milling
Packaging & Delivery
In coil, 1000feet or 305 meters per coil , coil on pallet
Company Profile
Shanghai Yila ,with high preciously equipment and rich experience, our company specilizes inmanufacturing master alloy, Magnesium anodes, Aluminum anodes, Zinc anodes, Aluminum base master alloy, Rare earth master alloy, Zinc base
master alloy, magnesium alloy billet,advanced Industrial Ceramics, and other new materials,
If your company uses the above products, please give us the opportunity to quote. We can be very competitive.Smaller quantities are welcome. Please give us a call and see if we can become one of your valued suppliers.
master alloy, magnesium alloy billet,advanced Industrial Ceramics, and other new materials,
If your company uses the above products, please give us the opportunity to quote. We can be very competitive.Smaller quantities are welcome. Please give us a call and see if we can become one of your valued suppliers.
