China road machinery TG220 grader machine Auto Level Grader hydraulic 220HP Motor Grader
- Category: >>>
- Supplier: Xiamen Tder Industrial Co. Ltd.
Share on (1600929052852):
Product Overview
Description
MODEL | TG135 | TG165 | TG175 | TG180 | TG190 | TG220 | |
Operating mass | kg | 13800 | 15000 | 15000 | 16000 | 16000 | 16900 |
Front axle load | kg | 4000 | 4150 | 4150 | 5150 | 5150 | 5820 |
Rear axle load | kg | 9800 | 10850 | 10850 | 10850 | 10850 | 11080 |
Max.forward speed | km/h | 38.3 | 40.4 | 40.4 | 36/38.2 | 36/38.2 | 36.8 |
Max.backward speed | km/h | 24.4 | 25.7 | 25.7 | 25/24.5 | 25/24.5 | 24.8 |
Speed gear number | F6/R3 | F6/R3 | F6/R3 | F6/R3 | F6/R3 | F6/R3 | |
Turning radius | mm | 7500 | 7500 | 7500 | 7800 | 7800 | 7800 |
Hydraulic system pressure | Mpa | 18 | 18 | 18 | 18 | 18 | 18 |
Blade length x height | mm | 3660x610 | 3660x610 | 3660x610 | 3965x610 | 3965x610 | 3965x610 |
Front wheeltrack | mm | 2150 | 2150 | 2150 | 2150 | 2150 | 2150 |
Rear wheeltrack | mm | 2165 | 2255 | 2255 | 2255 | 2255 | 2255 |
Wheelbase | mm | 5347 | 5347 | 5347 | 5647 | 5647 | 5647 |
Engine model | QSB5.9 | QSB5.9 | WP6G175E310 | QSB5.9 | WP6G190E330 | QSC8.3 | |
Engine power | kW | 97 | 125 | 129 | 132 | 140 | 158 |
Overall dimensions | mm | 8270x2495x3390 | 8605x2695x3420 | 8605x2695x3420 | 8605x2695x3420 | 8605x2695x3420 | 8605x2695x3420 |
