12v / 24v Off Road Self Rescue Electric Winch 12000 Pound Vehicle Electric Winch Automobile Winch
- Category: >>>
- Supplier: Hebei Jindiao Lifting Machinery Co. Ltd.
Share on (1600929865728):
Product Overview
Description
Products Description
DC 12V/24V Car Winch
Specifications:DC 12V Car Winch, mini 12v or 24v electric winch:
1. Capacity: 2000-12000lbs
2. Sling type: wire rope
3. Voltage: DC 12v or 24v
DC 12V Car Winch, mini 12v electric winch Introduction:
DC 12V/24V Car Winch is the most common winch, driven by vehicle's own power system. It works in such a way that converting automobile engines power into electricity power to drive the motors and drag noose. It enlarges the output power by the inside planetary reducer to achieve deceleration & torsion enhancement and pull cargo.
Product Features:
It is generally installed in the middle of the front car and connected with the car frame, exposed or hidden in the bumper.
Winch traction is valued by pound which can be converted to ton or kilogram. Do not exceed the rated traction.
The more cycles of winch wire rope on the reel, the less pull the outer cycle to bear.
The best advantage is that it can be normally used in condition of vehicle switch off while others can not.
Easy and multi-position installed, fast movable.
High density & high strength wire rope, durable and firm.
How to Choose Winch:
Make sure winch pull is 1.5 times of full loaded vehicle. A 8000-10000 pound winch is at least needed when vehicle is full loaded around 6000 pound.
Product Paramenters
MODEL | 2000 POUNDS | 3000 POUNDS | 3500 POUNDS | 4000 POUNDS |
output voltage | 12v/24v | 12v/24v | 12v/24v | 12v/24v |
Horizontal traction | 900kg | 1300kg | 1500kg | 1800kg |
Vertical lifting weight | 200kg | 500kg | 560kg | 800kg |
control mode | Manual | Manual | Manual | Manual/wireless |
No load speed | 5m/min | 5m/min | 5m/min | 5m/min |
Motor material | All copper motor | All copper motor | All copper motor | All copper motor |
Overall dimension (mm) | 286*100*105 | 299*100*105 | 340*110*112 | 353*110*112 |
MODEL | 4500 POUNDS | 6000 POUNDS | 9500 POUNDS | 12000 POUNDS |
output voltage | 12v/24v | 12v/24v | 12v/24v | 12v/24v |
Horizontal traction | 2025kg | 2700kg | 4300kg | 5400kg |
Vertical lifting weight | 800kg | 1100kg | 1400kg | 1550kg |
control mode | Manual/wireless | Manual/wireless | Manual / wireless | Manual/wireless |
No load speed | 5m/min | 5m/min | 5m/min | 5m/min |
Motor material | All copper motor | All copper motor | All copper motor | All copper motor |
Overall dimension (mm) | 332*116*115 | 415*160*217 | 527*160*217 | 527*160*217 |
Why Choose Us
Exhibition
Details Images
FAQ
1, Q: What are the trade terms we can be accepted?
A: EXW, FOB, CFR, CIF.
2, Q: What's your payment terms ?
A: We accept the payment sent by West Union, D/P,D/A,T/T or L/C at sight.
3,Q: How long does it take to execute my order?
Please tell us the quantity and model number of the products you are about to order, so that we will give you a detailed schedule.
4,Q: How can I know the completion of my order?
Upon receipt of the deposit, we will immediately arrange for the shippment, after the order is completed, we will also send you the detection images of your order before delivery for you to confirm.
5,Q: Can you arrange to deliver the goods for us?
Yes. When finish the orders, we will inform you and also we can arrange the shipping in the same time. There is LCL shipping and FCL shipping for different order term,the buyer also can choose Air-transport or Ocean shipping for your requirement .When your orders reach your local nearest Seaport or River port, the logistics company will infrom you.
6,Q: Can you guarantee your products?
Yes, we guarantee your 100% satisfaction on all our products.
Please feel free to feedback us immediately if you are not satisfied with our quality or service, If the product does not meet the contract requirements, we will send you a free replacement or give you compensation in the next order.
