PCB Assembly Service For Sensor Alarm Professional UL GSM Alarm System PCB PCBA FPC Board Manufacturer Factory PCBA
- Category: >>>
- Supplier: Shenzhen Uc Industrail Limited
Share on (1600930673203):
Product Overview
Description
Product Description
Product Description
Custom-Made OEM Electronic PCBA Assembly Manufacturer
Product Details
PCB Techinecal Capacity
Layers | Mass production: 2~58 layers / Pilot run: 64 layers |
Max. Thickness | Mass production: 394mil (10mm) / Pilot run: 17.5mm |
Material | FR-4 (Standard FR4, Mid-Tg FR4,Hi-Tg FR4, Lead free assembly material) , Halogen-Free, Ceramic filled , Teflon, Polyimide, BT, PPO, PPE, Hybrid, Partial hybrid, etc. |
Min. Width/Spacing | Inner layer: 3mil/3mil (HOZ), Outer layer: 4mil/4mil(1OZ) |
Max. Copper Thickness | UL certificated: 6.0 OZ / Pilot run: 12OZ |
Min. Hole Size | Mechanical drill: 8mil(0.2mm) Laser drill: 3mil(0.075mm) |
Max. Panel Size | 1150mm × 560mm |
Aspect Ratio | 18:1 |
Surface Finish | HASL,Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger |
Special Process | Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity, Hybrid, Partial hybrid, Partial high density, Back drilling, and Resistance control. |
PCBA technical Capacity
SMT | Position accuracy:20 um |
Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP | |
Max. component height::25mm | |
Max. PCB size:680×500mm | |
Min. PCB size:no limited | |
PCB thickness:0.3 to 6mm | |
PCB weight:3KG | |
Wave-Solder | Max. PCB width:450mm |
Min. PCB width: no limited | |
Component height:Top 120mm/Bot 15mm | |
Sweat-Solder | Metal type :part, whole, inlay, sidestep |
Metal material:Copper , Aluminum | |
Surface Finish:plating Au, plating sliver , plating Sn | |
Air bladder rate:less than20% | |
Press-fit | Press range:0-50KN |
Max. PCB size:800X600mm | |
Testing | ICT,Probe flying,burn-in,function test,temperature cycling |
Related Product
Our Service
U-C Group Limited is Electronic PCB & PCBA manufacturer
Specifications:
1.Fast and one-stop service
2.Accept PCB design,clone and OEM/ODM service.
3.PCB+Components+PCBA
4.Quote within 24 hours with China and US office.
Factory Show
Packing
Package:
Each products With ESD bags or do it on your request.
We provide a hard outer packing carton, to ensure that no problems during transport .
FAQ
Q: Are you amanufacturer?
A: Yes we are manufacturer.
Q: Do you provide samples?
A: Yes we can provide free samples, price and shipping cost open for negotiation.
Q: What certificates does this product have?
A: We have CE, FCC, ROHS certified.
Q: What about OEM and ODM?
A: We accept OEM and ODM orders, MoQ is open for discussion.
Q: What is depvery terms and time?
A: We use FOB terms and ship the goods in 7-30 days depend on your order quantity, customization.
